Keystone 35W 2x2 LED Center Basket Troffer with Power Select & Color Select Technology

(No reviews yet) Write a Review

Model: KT-CBLED35PS-22B-8CSA-VDIM

In Stock (leaves warehouse same day if ordered before 3pm ET)

$226.31
$190.46
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Keystone 35W 2x2 LED Center Basket Troffer with Power Select & Color Select Technology

Professional LED lighting solution with selectable power and color temperature options

The Keystone 35W 2x2 LED Center Basket Troffer delivers versatile professional lighting with innovative Power Select and Color Select technology. This ceiling-mounted fixture operates on 120-277V input voltage and features selectable power options of 35/30/24W with corresponding lumen outputs of 4400/3950/3200. The white housing provides clean integration while offering selectable color temperatures of 3500K/4000K/5000K to match any application requirement.

Professional Features & Benefits

  • Selectable Power Options (35/30/24W): Optimize energy consumption and light output for specific space requirements without changing fixtures
  • Color Select Technology (3500K/4000K/5000K): Adjust color temperature to create the ideal lighting environment for any professional setting
  • 0-10V Dimming Capability: Provides smooth dimming control for enhanced ambiance and additional energy savings
  • 50,000 Hour Rated Life: Delivers long-term reliability and reduced maintenance costs for commercial applications
  • DLC Listed: Qualifies for utility rebates and ensures energy efficiency compliance for commercial installations
  • 12V Auxiliary Power: Enables connection of emergency battery packs or other auxiliary devices for enhanced functionality
  • 10 Year Limited Warranty: Provides comprehensive coverage and confidence in long-term performance

Technical Specifications

  • Accessory Device: No
  • Cec T20: No
  • Cri: >80
  • Dimming: 0-10V
  • Dlc: Yes
  • Dlc Premium: No
  • Energy Star: No
  • Housing Color: White
  • Input Voltage: 120-277
  • Led Module Included: No
  • Mounting Method: Ceiling Mount
  • Nominal Size: 2x2
  • Not Suitable For Sale In California: No
  • Product Weight: 9.4 lbs
  • Rated Life Hours: 50000
  • Selectable Color Temperature: 3500/4000/5000
  • Selectable Lumens Output: 4400/3950/3200
  • Selectable Power: 35/30/24
  • T24 Ja8: No
  • Ul: No
  • Unique Features: 12V Aux Power
  • Warranty Years: 10 Year Limited
  • Wireless Control: No

Professional Applications

  • Commercial Office Buildings
  • Retail Establishments
  • Educational Facilities
  • Healthcare Facilities
  • Government Buildings
  • Professional Service Centers
  • Light Industrial Applications

Why Choose Keystone Quality?

Keystone delivers reliable LED lighting solutions backed by a comprehensive 10 Year Limited warranty and DLC listing for energy efficiency compliance. The durable white housing construction and 50,000-hour rated life ensure long-term performance in demanding commercial environments.

Manufacturer Resources

Product Specs

Accessory Device:
No
Cec T20:
No
Cri:
>80
Dimming:
0-10V
Dlc:
Yes
Dlc Premium:
No
Energy Star:
No
Housing Color:
White
Input Voltage:
120-277
Led Module Included:
No
Mounting Method:
Ceiling Mount
Not Suitable For Sale In California:
No
Product Weight:
9.4 lbs
Rated Life Hours:
50000
Selectable Color Temperature:
3500/4000/5000
Selectable Lumens Output:
4400/3950/3200
Selectable Power:
35/30/24
T24 Ja8:
No
Ul:
No
Unique Features:
12V Aux Power
Warranty Years:
10 Year Limited
Wireless Control:
No
Product Nominal Size:
2x2

Keystone KT-CBLED35PS-22B-8CSA-VDIM – Frequently Asked Questions

1) Will the Keystone 2x2 center basket troffer drop into a standard 2x2 grid ceiling?
It's a 2x2 nominal fixture and ceiling mount, so it goes into a 2-foot by 2-foot grid opening. Model KT-CBLED35PS-22B-8CSA-VDIM weighs 9.4 lbs, light enough for standard grid with proper support wires per code.
2) Can I run this troffer on 208V or 277V building power?
Yes. The driver accepts 120-277V, so it works on 120, 208, 240 or 277 volt circuits without a different part number. That's one SKU you can standardize on across a mixed-voltage portfolio.
3) How do I set the wattage and color temperature on a Keystone Power Select / Color Select troffer?
Both are selectable at the fixture rather than ordered as separate models. Power Select gives 35W, 30W or 24W, producing 4400, 3950 or 3200 lumens respectively. Color Select gives 3500K, 4000K or 5000K. You pick both during install, so one stocked fixture covers multiple space types and you are not carrying nine SKUs on the shelf.
4) Is this troffer compatible with my 0-10V dimming system?
Dimming is 0-10V, so it ties into standard low-voltage analog dimming controls and occupancy/daylight systems that output 0-10V. It has no built-in wireless control, so any networked control has to come from your external system or a separate node.
5) Can I add an emergency battery backup to this LED troffer?
It carries 12V auxiliary power, which is what an emergency battery pack or similar auxiliary device connects to. The battery pack itself is a separate item and is not included with the fixture.
6) Is the color rendering good enough for retail and healthcare spaces?
CRI is greater than 80, which covers typical office, retail, education and healthcare general lighting. For color-critical retail display or task areas where a 90+ CRI spec is written, you'd want a higher-CRI fixture instead.
7) Do I need to buy LED modules or lamps separately for this troffer?
No lamps to buy. The fixture is an integrated LED troffer, rated 50,000 hours, with no separate replaceable LED module to order. Maintenance planning should treat it as a sealed fixture.
8) Will the white housing match the other troffers already in my ceiling?
The housing is white, the standard finish on commercial recessed troffers, so it blends with existing white grid and white-painted fixtures. The center basket design puts a diffusing basket at the middle of the fixture rather than a flat full-face lens, so visually it will not be identical to a flat-lens troffer in the same ceiling run.
