3M 7000031851 3M™ Cable Tie CT...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.16
$0.18
3M 7000031851 3M™ Cable Tie CT8NT18-C, 1000/Case

3M 7000031851 3M™ Cable Tie CT8NT18-C, 1000/Case

(No reviews yet) Write a Review

Model: 7000031851
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.16
$0.18
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
3M™ Cable Tie CT8NT18-C, 1000/Case

  • Features

    • Made in the USA
    • UL Listed 62275 Type 21 or 21S and Plenum Rated AH-2 for use in air handling spaces
    • Curved tip allows for faster threading and installation
    • Secure wire bundles and harness components quickly, without slipping


7000031851 - spec sheet

Manufacturer Resources

Product Specs

Ais Url Article Information Sheet:
https://multimedia.3m.com/mws/mediawebserver?mwsId=SSSSSu9n_zu8l00xMY_ZP82xNv70k17zHvu9lxtD7xtBevSS
Cable Diameter Range:
8,1 - 39,4 mm
Cable Length Imperial:
8.0 in
Cable Length Metric:
205.74 mm
Cable Management Products:
Cable Ties
Cable Tie Base Height:
8 in
Cable Tie Length:
193.0 mm
Cable Tie Type:
Miniature
Country Of Origin:
Honduras
Etim Class 8 0:
EC000046
Flammability Rating:
UL 94 V-2
Manufacturing Origin:
USA
Maximum Bundle Diameter:
2 Inch
Maximum Bundle Diameter Metric:
50.8 mm
Maximum Insulation Outer Diameter Metric:
3.7 mm
Maximum Insulation Outside Diameter:
0.145 in
Maximum Operating Temperature:
85 Degree Celsius
Maximum Operating Temperature Celsius:
85.0 Degree
Maximum Operating Temperature Fahrenheit:
185.0 Degree
Maximum Recommended Voltage Rating:
600.0 V
Minimum Bundle Diameter:
0.0625 Inch
Minimum Bundle Diameter Metric:
1.6 mm
Minimum Installation Temperature Celsius:
0 Degree Celsius
Minimum Operating Temperature Celsius:
-40.0 Degree
Minimum Operating Temperature Fahrenheit:
-40.0 Degree
Operating Temperature Celsius:
85 Degree Celsius
Operating Temperature Fahrenheit:
185 Degree Fahrenheit
Operating Temperature Range Celsius:
-40 °C to 85 °C
Operating Temperature Range Fahrenheit:
-40 °F to 185 °F
Overall Length Imperial:
8.1 in
Overall Length Metric:
206.0 mm
Overall Width Imperial:
0.096 in
Overall Width Metric:
2.4 mm
Package Quantity:
100.0 PCS
Plenum Rated:
Yes
Product Material:
Nylon 6/6
Product Type:
Cable Ties
Rds Url Regulatory Data Sheet:
https://cdmsweb.3m.com/ingredientcommunication/file/Media/I14sCjuQlxU=
Rohs Eu Comments:
RoHS 2011/65/EU compliant without exemption
Solution For:
Longhaul/Metro Loop Network: Outdoor
Tensile Strength Imperial:
18 lbs
Tensile Strength Metric:
8.17 kg
Ul Approval:
Yes
Units Per Bag:
100
Units Per Case:
1000
Uv Resistant:
No
Department:
Electrical
Product Subgroup:
Cable Ties & Mounts

3M 7000031851 – Frequently Asked Questions

1) Can the 3M CT8NT18-C cable tie be used in a plenum or air handling space?
Yes. The CT8NT18-C is plenum rated and UL Listed to 62275 Type 21 or 21S, with an AH-2 plenum rating for use in air handling spaces. That is the rating inspectors look for when ties are run above a ceiling being used as a return air plenum.
2) Will these 3M nylon cable ties hold up outdoors in sunlight?
No. The CT8NT18-C is natural Nylon 6/6 and is not UV resistant, so sustained sun exposure will degrade it. For exposed outdoor runs use a black UV-stabilized tie instead. It is listed for outdoor longhaul/metro loop network work, but that assumes shielded or enclosed placement rather than direct sunlight.
3) What temperature range can these cable ties be installed and run in?
Operating range is -40 C to 85 C (-40 F to 185 F). Installation is a different number: do not install below 0 C, because cold nylon gets brittle and the strap can crack as you cinch it.
4) What is the flammability and voltage rating on the 3M CT8NT18-C cable tie?
Flammability is UL 94 V-2, and the maximum recommended voltage rating is 600 V. It is also RoHS 2011/65/EU compliant without exemption, which matters if you are specifying for a facility with restricted-substance requirements.
5) How many 3M CT8NT18-C ties come in a case and how are they packed?
The case holds 1,000 ties, bagged 100 to a bag. That packaging suits a truck stock or MRO crib where you pull a bag at a time rather than opening the whole case.
