3M 7000133235 3M™ Cold Shrink End Cap EC-2, use range of 0.63-1.18 in (15,9-30,1 mm), 10/case

The EC-2 cold shrink end cap covers cable or pipe ends from 0.63 to 1.18 inches (15.9 to 30.1 mm) in diameter. The 1.18 in (30.1 mm) figure is the inner diameter before shrink, so anything larger than that will not load over the end; the 0.63 in (15.9 mm) recovered diameter is the smallest it will grip down onto. Measure over the cable jacket, including any tape buildup, before choosing the size.

No heat at all. The EC-2 is a cold shrink product: the EPDM sleeve is pre-stretched over a removable plastic core, you slide it into position and unwind the core, and the rubber contracts onto the cable on its own. No torch, no heat gun, no tools. That is the main reason crews use cold shrink instead of heat shrink in trenches, vaults, and anywhere a flame is not allowed.

That is one of its normal uses. The EC-2 is a close-ended tubular sleeve, so it seals the cut end completely rather than just wrapping it. The EPDM rubber resists water, alkalis, acids, abrasion and ozone, which is what keeps moisture out of the conductor while the reel or the pulled-in run sits before termination. It also gives the exposed end some physical protection during handling.

Ten caps per case. Part number 7000133235 is the EC-2 size, so every cap in the box covers the same 0.63 to 1.18 inch range. If you are capping a mix of cable sizes on a job, you will need a second size in addition to this one.

Yes. The EC-2 is made from EPDM rubber that contains no chlorides or sulfur, which matters where those compounds could attack or stain the cable jacket or nearby metallic components. The cap is black.

It is RoHS 2011/65/EU compliant without exemption, which is the cleanest form of that declaration for procurement files. 3M also publishes a regulatory data sheet and an article information sheet for the part if your submittal package needs supporting documentation. Country of origin is China.

Yes. The EC-2 provides water resistance and physical protection for cables and pipes alike, so it works as a temporary or protective cap on small-diameter tube and conduit ends within the same 0.63 to 1.18 inch (15.9 to 30.1 mm) range. Size it by the outside diameter of whatever it is going over.

3M lists a shelf life of 1800 days for the EC-2, roughly five years from manufacture. Because the sleeve sits pre-expanded on its core the whole time, store the case indoors and out of direct sun, and use older stock first.
