Scotchlok Female Disconnect Terminal 16-14 AWG Vinyl Insulated Blue 600V Rated

Scotchlok Female Disconnect Terminal 16-14 AWG Vinyl Insulated Blue 600V Rated

Professional Wire Connection Solution with Superior Holding Force

The Scotchlok Female Disconnect Terminal delivers reliable wire connection performance for 16-14 AWG conductors with 600V rating for building wire applications. Featuring durable brass construction with tin-plated finish for corrosion resistance, this blue vinyl-insulated terminal withstands temperatures from -40 to 221�F (-40 to 105�C). The butted-seam barrel design with funnel-shaped polyvinyl chloride sleeve ensures easy wire insertion while providing electrical contact and mechanical stress relief.

Professional Features & Benefits

• 16-14 AWG Wire Compatibility: Accommodates standard building wire sizes for versatile electrical connection applications
• 600V Rating: Provides reliable voltage handling for building wire with additional 1000V rating for signs, fixtures, and luminaires
• Durable Brass Construction: Ensures excellent conductivity with tin-plated finish that resists corrosion for long-term reliability
• Temperature Range -40 to 221�F: Maintains performance across extreme temperature conditions for indoor and outdoor applications
• Dents and Rolled Edges: Engineered design provides superior holding force while allowing quick and easy wire disconnect when needed
• UL Listed and CSA Certified: Meets rigorous safety standards with RoHS 2011/65/EU compliance for professional installations
• Blue Vinyl Insulation: Color-coded identification with abrasion-resistant sleeve that provides electrical insulation and mechanical protection

Technical Specifications

• 3m Id: 80611458169
• Agency Approvals: UL and CSA
• Barrel Length: 0.25 Inch
• Barrel Style: Butted
• Conductor Size: 16 - 14 AWG
• Conductor Sizes: 16 - 14 AWG
• Connection Type: Wire
• Connector Style: Insulation Displacement
• Csa File Number: LR22190
• Diameter Metric : 5.8
• Fastener Orientation: Female
• Flame Retardant: No
• Insulation Material: Vinyl
• Length Metric : 22.09 mm
• Mates With Male Tab Width W : 0.25 Inch
• Maximum Insulation Outer Diameter: 0.145 Inch
• Maximum Operating Temperature Celsius : 105 Degree Celsius
• Maximum Operating Temperature Fahrenheit : 221 Degree Fahrenheit
• Maximum Recommended Voltage Rating: 600 V
• Maximum Wire Gauge: 14 AWG
• Minimum Wire Gauge: 16 AWG
• National Stock Number: 5.94001E+12
• Packaging: 100 per bottle
• Pad Width: 0.25 Inch
• Product Brand: Scotchlok�
• Product Color: Blue
• Product Diameter: 0.23 Inch
• Product Length: 0.87 Inch
• Product Material: ETP Copper
• Product Width: 0.37 Inch
• Rohs 2011 65 Eu Compliant: Yes
• Rohs Eu Comments: RoHS 2011/65/EU compliant without exemption
• Solution For: Wireless Network: Infrastructure Accessories
• Terminal Style: Standard
• Terminal Type: Disconnect
• Thickness: 0.032 Inch
• Thickness Metric : 0.81 mm
• Trademark: Scotchlok
• Ul File Number: E70512
• Width Metric : 9.4

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Building Wire Connections in Residential and Commercial Electrical Systems
• Control Panel and Electrical Enclosure Wiring
• Sign and Fixture Connections for Lighting Applications
• Luminaire Wiring and Electrical Component Connections
• Wireless Network Infrastructure and Telecommunications Equipment
• Industrial Equipment and Machinery Wire Connections
• Maintenance and Repair Applications Requiring Quick Disconnect Capability

Why Choose Scotchlok Quality?

Scotchlok terminals deliver proven reliability with UL Listed and CSA Certified safety compliance, backed by RoHS 2011/65/EU environmental standards. The durable brass construction with tin-plated finish ensures long-term performance in demanding electrical applications, while the engineered design provides superior holding force for secure connections.
