3M Scotchlok Fork Terminal Vinyl Insulated 22-18 AWG #10 Stud with Wider-Tongue Design

3M Scotchlok Fork Terminal Vinyl Insulated 22-18 AWG #10 Stud with Wider-Tongue Design

Professional electrical connections with enhanced stud compatibility

The 3M Scotchlok Fork Terminal delivers reliable electrical connections for 22-18 AWG conductors with #10 stud compatibility. Featuring red vinyl insulation and a brazed-seam barrel construction, this terminal provides secure connections with enhanced performance. The wider-tongue design specifically accommodates free-standing studs, while the funnel-designed polyvinyl chloride sleeve ensures easy wire insertion for professional installations.

Professional Features & Benefits

• 22-18 AWG Conductor Range: Accommodates common wire sizes for versatile electrical connection applications
• #10 Stud Compatibility: Designed for standard stud sizes with wider-tongue design for enhanced fit on free-standing studs
• Brazed-Seam Barrel: Ensures secure mechanical connection and reliable long-term performance
• Red Vinyl Insulation: Provides electrical insulation and color coding for easy identification during installation
• Funnel-Designed Sleeve: Polyvinyl chloride construction offers easy wire insertion and secure grip
• USA Manufacturing: Manufactured in USA ensuring consistent quality and reliable supply chain
• 100-Piece Bottle: Convenient packaging for professional contractors and maintenance applications

Technical Specifications

• Barrel Inside Diameter: 0.070 Inch
• Barrel Style: Brazed
• Clearance C: 0.29 Inch
• Conductor Size: 22 - 18 AWG
• Dimension E: 0.74 Inch
• Fork Type: Standard
• Insulation Material: Vinyl
• Manufacturer Catalog Number: 7100098431
• Manufacturing Origin: USA
• Maximum Conductor Size: 18 AWG
• Maximum Insulation Outer Diameter Imperial: 0.145 Inch
• Minimum Conductor Size: 22 AWG
• Overall Length Imperial: 0.9 in
• Overall Width Imperial: 0.34 in
• Package Height: 4.37500 in
• Package Length: 1.62500 in
• Package Weight: 0.3961 LBS
• Stud Size: #10
• Terminal Style: Standard
• Terminal Type: Fork

Installation & Operation

1. Strip conductor insulation to appropriate length ensuring clean, straight cut for optimal connection.
2. Insert stripped conductor into the funnel-designed sleeve until wire is fully seated in the brazed barrel.
3. Crimp the terminal using appropriate crimping tool to manufacturer specifications for secure connection.
4. Position the fork terminal over the #10 stud, ensuring the wider-tongue design properly engages free-standing studs.
5. Secure with appropriate fastener, applying proper torque specifications for the stud size and application.
6. Verify connection integrity and ensure proper electrical continuity before energizing the circuit.

Professional Applications

• Electrical panel connections and distribution equipment
• Control circuit wiring and automation systems
• Industrial machinery and equipment connections
• Commercial building electrical installations
• Maintenance and repair operations
• Telecommunications and data center infrastructure
• HVAC system electrical connections

Why Choose 3M Quality?

3M Scotchlok terminals are manufactured in the USA with consistent quality standards and reliable performance. The brazed-seam barrel construction and vinyl insulation provide long-term durability in professional electrical applications, while the wider-tongue design ensures compatibility with free-standing stud configurations for enhanced installation flexibility.
