4 Terminal Ringless Large Closing Plate Lever Bypass Pepco
Manufacturer Resources
Product Specs
- Amperage Rating:
- 320 Continuous Ampere
- Application:
- Meter Socket
- Brand Name:
- Milbank
- Bypass Provision:
- Lever Bypass
- Cable Entry:
- Overhead and Underground and Side Wireway
- Equipment Ground:
- Ground Lug
- Frequency Rating:
- 60 Hertz
- Height:
- 31.5 IN
- Hub Closing Plate:
- Large Closing Plate
- Insulation:
- Glass Polyester
- Length:
- 4.844 IN
- Main Breaker Size:
- No Main Breaker
- Material:
- G90 Galvanized Steel with Powder Coat Finish
- Mounting:
- Surface Mount
- Number Of Jaws:
- 4 Terminal
- Number Of Main Breakers:
- 0
- Number Of Meter Positions:
- 1 Position
- Number Of Receptacles:
- 0
- Phase:
- 1 Phase
- Product Family Code:
- 4T32
- Size:
- 4.844L x 15W x31.5H
- Special Features:
- Potomac Electric Power Company
- Standard:
- UL Listed;Type 3R
- Terminal:
- 3/8 Inch Stud
- Type:
- Ringless Meter Socket
- Unspsc Number:
- 39121102
- Voltage Rating:
- 600 Volts Alternating Current
- Width:
- 15 IN
