Keystone KTEB-432-UV-IS-N-P-DP 4 x F32T8

Yes. The KTEB-432-UV-IS-N-P-DP is a universal voltage ballast, accepting 120 through 277 volts on the same unit. That's what the UV in the model number means, and it's why maintenance crews stock one part for both the 120V circuits in an office area and the 277V circuits feeding a warehouse or parking structure.

It drives four F32T8 lamps, and it can also be wired to run three. That flexibility matters on a retrofit where one fixture in a run has a lamp position deleted or a broken socket you're abandoning: same ballast covers both the 4-lamp and 3-lamp troffers, so you aren't buying two part numbers for one building.

No. This is a non-dimming electronic T8 ballast with no wireless control capability, so it runs the lamps at full output only. Put it on a switched circuit or a simple on/off occupancy sensor. If the spec on the job calls for daylight harvesting or step dimming, you need a dimming ballast or an LED driver instead, not this one.

It's a fluorescent ballast, not an LED driver, and no LED module ships with it. It's built to operate F32T8 linear fluorescent lamps and the lamps are sold separately. If you're converting a fixture to LED, a ballast-bypass tube or an LED driver is the right direction, not this part.

It's an instant start ballast, which is what the IS in the model designation indicates. Instant start strikes the lamps without preheating the cathodes, which gives the most efficient operation but shortens lamp life in spaces that cycle frequently. In a restroom or stairwell on a motion sensor that switches many times a day, a programmed start ballast is the better choice; for offices, corridors and retail that stay on for hours at a time, instant start is the normal spec.

No harness. It ships with standard wire leads, so you'll be stripping and splicing to the lamp sockets with wire nuts or push connectors in the fixture channel. Budget the connectors as a separate line item if you're doing a volume re-ballast.

It doesn't. The KTEB-432 is not DLC listed, not DLC Premium, and not ENERGY STAR. Rebate programs for linear lighting have largely moved to LED anyway, so if the project is being funded off a utility incentive, you'll want a DLC-listed LED retrofit kit rather than a fluorescent re-ballast.

Each ballast is 1.21 lbs. Useful math when you're pricing freight on a case quantity for a multi-building re-lamp, or checking what a single service van can carry for a day of troffer work.
