6 x 1-1/2 in. Flat Head Phillips Wood Screws - 18-8 Stainless - 100qty
Features
- Stainless wood screws are usually supplied without additional finish
- 6 Diameter, 1-1/2" Length
- Flat Head with Phillips Drive
- Screws of nominal lengths too short to accomodate the minimum thread length shall have threads extending as close to the underside of the head as practicable.
- 18-8 Stainless Material
Additional Notes
- Other sizes and quantities available by request | Length of Thread: Length = 1 inch then 2/3 thread
Manufacturer Resources
Product Specs
- Minimum Purchase:
- 100 units
- Arra Compliant:
- N
- Buy American Compliant:
- No
- Dimensional Standard:
- ASME B18.6.1
- Division:
- Electrical H1
- Drive Type:
- Phillips
- Driver Size:
- #2
- Fastener Head Height:
- 0.083 in.
- Fastener Head Type:
- Flat
- Fastener Head Width:
- 0.244 - 0.279 in.
- Fastener Length:
- 1/1/02
- Field Application:
- Electrical, Plumbing, Heating, Air Conditioning Industries
- Language Code:
- EN
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Flat_Head_Wood_Screw_Steel_SS.pdf
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- JR
- Pack Type:
- Jar
- Phillips Recess Depth:
- 0.083 - 0.106
- Phillips Recess Diameter:
- 0.161 - 0.174
- Phillips Recess Width:
- 0.029
- Product Group:
- Fasteners
- Product Height:
- 2.15 in
- Product Length:
- 3 in
- Product Weight:
- 0.49 lbs
- Product Width:
- 3 in
- Screw Point Type:
- Tapered Point
- Sub Division:
- Electrical-E H2
- Thread Per Inch:
- 18
- Thread Standard:
- ASME B18.6.1-1997
- Department:
- Electrical
- Product Subgroup:
- Screws
- Product Type:
- Wood Screw
- Type2:
- Wood Screw
- Series:
- JFWP
- Product Details:
- Wood Screw
- Product Material:
- 18-8 Stainless
Metallics JFWP13SS – Frequently Asked Questions
1) How many Metallics JFWP13SS wood screws come in a pack?
The JFWP13SS ships as a jar of 100 screws, and 100 is the order minimum. So the "each" you add to a cart is one 100-count jar, not a single screw. Handy for a truck stock bin where you want #6 stainless on hand without opening a bulk box.
2) Will 18-8 stainless wood screws hold up outdoors or in a damp location?
These are 18-8 stainless, the common austenitic grade used where plain steel would rust, so they suit damp interiors, covered exteriors, and general corrosion-prone work. Stainless wood screws like these are normally supplied bare with no added plating or coating, so what you see is the finish. For direct saltwater exposure most specs call for a 316 grade instead.
3) Will a #6 flat head screw sit flush in a countersunk hole?
Yes, it's built to. The flat head measures 0.244 to 0.279 inch across with a head height of 0.083 inch, so a standard 82 degree countersink for a #6 brings it flush or just below. In softwood you can usually pull it flush without countersinking; in hardwood or when fastening metal plates and straps, countersink first so the head doesn't dimple the material.
4) Are Metallics JFWP13SS screws Buy American or ARRA compliant for a government job?
No. These are not Buy American compliant and are not ARRA compliant, with country of origin listed as multiple. If your project carries a domestic-sourcing clause, you'll need a fastener sourced specifically for that requirement.
5) What size Phillips bit do I need for these #6 wood screws?
A #2 Phillips driver. The recess runs 0.161 to 0.174 inch in diameter with a 0.083 to 0.106 inch depth, which is the standard #2 recess on a #6 screw. Stainless cams out easier than hardened steel, so keep the bit seated and the clutch low.
6) Do these screws meet a recognized dimensional standard for spec work?
They're made to ASME B18.6.1, with the thread conforming to ASME B18.6.1-1997. That's the standard for wood screws, so head geometry, thread form, and point all fall within published tolerances rather than a house dimension. Useful when a submittal or an inspector wants a referenced standard on the fastener.
7) How much of a 1-1/2 inch wood screw is actually threaded?
On a #6 x 1-1/2 inch wood screw the thread covers roughly two thirds of the length, leaving a smooth shank under the head. That unthreaded shank is what lets the top board pull tight against the bottom one instead of jacking apart. Thread count is 18 per inch with a tapered point, so it starts in softwood without a pilot, though hardwood still wants one.
