Metallics JTEK71P 6 x 1-1/2 in...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.33
$0.33
Metallics JTEK71P 6 x 1-1/2 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 100qty

Metallics JTEK71P 6 x 1-1/2 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JTEK71P
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.33
$0.33
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
6 x 1-1/2 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 100qty

  • Additional Notes

    • Other sizes and quantities available by request | SAE J78 does not include Specifications for #7 diameter drill screws. | This table is only a guide and does not constitute a warranty of any type.

  • Features

    • Pan Head with Phillips Drive
    • Steel Zinc Material
    • 6 Diameter, 1-1/2" Length
    • #2 Drill Point

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drill Point Size:
#2
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Height:
0.087 - 0.097 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.256 - 0.27 in.
Fastener Length:
1/1/02
Hardness:
Rockwell C32-40
Language Code:
EN
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Panel Thickness:
0.035 - 0.090 IN
Phillips Recess Diameter:
0.159
Product Group:
Fasteners
Recess Penetration Gaging Depth:
0.055 - 0.080
Screw Point Type:
Drill Point
Sub Division:
Electrical-E H2
Thread Per Inch:
20
Thread Standard:
SAE J78 - 2013
Torsional Strength:
24 lb-in minimum
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type BSD Self-Drilling & Tapping Screw
Type2:
Type BSD Self-Drilling & Tapping Screw
Series:
JTEK
Product Finish:
Zinc
Product Details:
Type BSD Self-Drilling & Tapping Screw
Product Material:
Steel Zinc

Metallics JTEK71P – Frequently Asked Questions

1) Do I need a pilot hole for the Metallics JTEK71P screws?
No. It is a Type BSD self-drilling and tapping screw with a drill point, so it bores and forms its own thread in one pass through sheet metal within the 0.035 to 0.090 in. panel range. No pre-drilling, no separate tapping step.
2) Do these Metallics drill screws meet Buy American or ARRA requirements for a government job?
No. The JTEK71P is listed as not Buy American compliant and not ARRA compliant, with country of origin shown as multiple. On a federally funded project with domestic-sourcing language in the spec, these will not qualify and you need a domestically produced fastener instead.
3) What driver bit do I need for these Phillips pan head self-drilling screws?
A #2 Phillips bit. The recess is a Phillips drive with a 0.159 in. recess diameter and a gaging depth of 0.055 to 0.080 in., so a #2 seats fully. Running a #1 or #3 is how you strip the recess at the torque these take.
4) How much torque will these screws take before the head twists off?
24 lb-in minimum torsional strength, with the screw heat treated to Rockwell C32-40. Set your driver clutch under that. On a cordless impact at full setting a #6 shank will shear before the head seats, so dial it back or use a drill/driver with a depth-sensing nose.
5) Will a pan head sit flush, or does it stand above the surface?
Pan head, so it stands proud. Head height runs 0.087 to 0.097 in. and head width 0.256 to 0.27 in., giving a low rounded crown with a flat bearing underside that spreads load on sheet metal. If you need the fastener flush or below the surface, a flat or trim head is the one to use instead, not this.
6) Are these zinc screws OK for outdoor or damp electrical work?
Steel with a zinc finish is a plated carbon steel fastener, intended for dry interior use such as panel, strut, box and sheet metal work. Zinc plating is not a marine or sustained wet-location coating. For exterior or wash-down conditions, specify a stainless or a hot-dip/coated exterior screw rather than the zinc-plated JTEK71P.
7) What standards do these self-drilling tapping screws conform to?
Threads are to SAE J78 - 2013 and head dimensions follow ASME B18.6.3-2010. That is the usual pair of callouts on a submittal for Type BSD drill screws. Note SAE J78 carries no specification for a #7 diameter drill screw, so if a drawing calls out #7 you are outside the standard regardless of supplier.
8) How are these sold, and what is the minimum I can order?
Sold in a jar of 100, which is also the order minimum (100 count). So one unit on the order is one 100-piece jar of the #6 x 1-1/2 in. pan head drill screws, not a single screw.
9) Can I get the JTEK71P screw in a different length or a larger jar count?
Yes. Other sizes and quantities of the Metallics JTEK pan head Phillips drill screw are available by request, so if a job needs a shorter shank or a bulk count beyond the 100-piece jar, it can be sourced.
