Metallics JTEK11PV 6 x 3/4 in....
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.19
$0.19
Metallics JTEK11PV 6 x 3/4 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 500qty

Metallics JTEK11PV 6 x 3/4 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JTEK11PV
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.19
$0.19
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
6 x 3/4 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 500qty

  • Additional Notes

    • Other sizes and quantities available by request | SAE J78 does not include Specifications for #7 diameter drill screws. | This table is only a guide and does not constitute a warranty of any type.

  • Features

    • Steel Zinc Material
    • #2 Drill Point
    • 6 Diameter, 3/4" Length
    • Pan Head with Phillips Drive

Manufacturer Resources

Product Specs

Minimum Purchase:
500 units
Arra Compliant:
C
Buy American Compliant:
C
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drill Point Size:
#2
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Color:
Silver
Fastener Head Height:
0.087 - 0.097 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.256 - 0.27 in.
Fastener Length:
4-Mar
Hardness:
Rockwell C32-40
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Hd_Phil_Self-Drill_TS_Steel_and_SS.pdf
Order Minimum Imperial:
500
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Panel Thickness:
0.035 - 0.090 IN
Phillips Recess Diameter:
0.159
Product Group:
Fasteners
Product Height:
2.7 in
Product Length:
3 in
Product Weight:
1.6 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.055 - 0.080
Screw Point Type:
Drill Point
Sub Division:
Electrical-E H2
Thread Per Inch:
20
Thread Standard:
SAE J78 - 2013
Thread Type:
UNC
Torsional Strength:
24 lb-in minimum
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type BSD Self-Drilling & Tapping Screw
Type2:
Type BSD Self-Drilling & Tapping Screw
Series:
JTEK
Product Finish:
Zinc
Product Details:
Type BSD Self-Drilling & Tapping Screw
Product Material:
Steel Zinc

Metallics JTEK11PV – Frequently Asked Questions

1) Will a #6 x 3/4 in. self-drilling screw hold in a metal stud without a pilot hole?
No pilot hole needed. It is a Type BSD self-drilling and tapping screw, so the drill point cuts its own hole and the 20 threads-per-inch UNC thread taps as it goes. One driver pass, no pre-drill, as long as the steel is within the 0.035 to 0.090 in. range.
2) What driver bit do I need for the JTEK11PV pan head screw?
A #2 Phillips bit. The recess is a Phillips drive with a 0.159 in. recess diameter and a gaging depth of 0.055 to 0.080 in., so a worn or oversized bit will cam out. The screw is rated to 24 lb-in minimum torsional strength, which is the point to stay under on an impact driver.
3) Is zinc plated steel good enough for outdoor or damp locations?
The JTEK11PV is steel with a zinc finish, which is a dry indoor-duty plating. For exterior, wet, or corrosive locations, specify a stainless self-drilling screw instead of the zinc plated version.
4) Does the pan head on this screw sit flush, and how much does it stand off the surface?
Pan head, so it does not sit flush; it bears on the surface. Head height runs 0.087 to 0.097 in. and head width 0.256 to 0.27 in., which gives a broad bearing face for fastening straps, plates, and box mounting. If you need a flush surface, use a flat head screw in a countersunk hole instead.
5) How many Metallics JTEK11PV screws come in a jar, and can I buy fewer?
Minimum order is 500 count, packed in a jar. It is sold by the jar rather than loose, so 500 is the smallest quantity.
6) Does the JTEK11PV meet Buy American and ARRA requirements for a government job?
Both flags are marked compliant on the JTEK11PV, with country of origin listed as multiple. For a federal or publicly funded project, have the supplier confirm the origin on the specific lot shipped.
7) What standards does this #6 self-drilling screw conform to?
Dimensions follow ASME B18.6.3-2010 and the thread follows SAE J78 - 2013. Hardness is Rockwell C32-40, the case hardness range that lets the point drill steel without snapping the shank. Note that SAE J78 does not cover #7 diameter drill screws, so a submittal calling out a #7 will not reference that standard.
8) Will a 3/4 in. long screw be too long for fastening into a metal stud?
At 3/4 in. of length with a #6 diameter, there is enough shank for the drill point plus thread engagement in 0.035 to 0.090 in. steel, and the tip will protrude past the back of the panel. On a finished wall face or anywhere a projecting point is a hazard, step down to a shorter length in the same series.
