91670 Viega MegaPress tee Smart Connect technology 316 stainless steel, 1-1/2'' x 1-1/2'' x 1''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2 x P3
- Material Type:
- 316 Stainless Steel
- Product Dimension:
- 1-1/2'' x 1-1/2'' x 1''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 6.953"
- Product Height:
- 2.437"
- Product Weight:
- 1.651 lbs
- Product Width:
- 4.059"
- Product Material:
- 316 stainless steel
Viega 91670 – Frequently Asked Questions
1) What pipe sizes does the Viega MegaPress 91670 tee connect?
The Viega MegaPress 91670 is a reducing tee sized 1-1/2 inch x 1-1/2 inch x 1 inch, so the run is 1-1/2 inch on both ends and the branch outlet is 1 inch. All three ends are press connections (P1 x P2 x P3), not threaded or grooved, so you press onto black, galvanized or other iron pipe rather than cutting threads.
2) Is the Viega 91670 tee stainless steel or carbon steel?
It is 316 stainless steel, body and all three press ends. That matters on the job: 316 is the grade you want for corrosive or wash-down service and for compatibility with stainless pipe systems, where a carbon steel MegaPress fitting would not be appropriate. The fitting is made in Germany.
3) Can I use the 91670 tee to drop a 1 inch branch off an existing 1-1/2 inch iron pipe line?
That is exactly the configuration. The two 1-1/2 inch ends go in line with the main and the 1 inch end takes the branch. Because the ends are press rather than threaded, you cut and prep the existing pipe in place instead of breaking down the line to thread it, which is why this style gets used for retrofit takeoffs in occupied buildings.
4) How much clearance do I need around a 1-1/2 inch MegaPress tee to get the press tool jaw on it?
Plan your layout around the fitting envelope: 6.953 inches long, 4.059 inches wide, 2.437 inches high. The 91670 weighs 1.651 lbs. Those numbers tell you the center-to-end reach on the run and the branch projection, which is what decides whether a press jaw or ring will clear adjacent pipe, joists or wall framing on a tight retrofit.
5) What does Smart Connect do on a Viega MegaPress fitting?
Smart Connect is a feature of the sealing element that lets an unpressed connection leak intentionally during pressure testing, so you can find a joint you missed before the system goes into service. On the 91670 tee it applies at all three press ends, which is useful when you are branching a 1 inch takeoff off a 1-1/2 inch main inside a chase and one end is easy to overlook.
6) Do I need a special press tool or jaws to install a 1-1/2 inch MegaPress tee?
MegaPress is a press system, so the joint is made with a press tool, not with threads or solvent. A 1-1/2 inch connection is in the larger size range, which is typically pressed with a ring and actuator rather than a standard small jaw. Order the ring and actuator that match the 1-1/2 inch run and the 1 inch branch separately; the tee itself ships as the fitting only.
7) What is the exact part number to order this Viega 1-1/2 x 1-1/2 x 1 stainless MegaPress tee?
Order Viega MegaPress part number 91670. That number covers the 316 stainless steel tee in 1-1/2 inch x 1-1/2 inch x 1 inch with press ends on all three openings. Quote the 91670 and the size together when confirming with a wholesaler, since Viega also builds the same configuration in carbon steel under a different number.
