93511 Viega PureFlow Press stop valve Angled Zero Lead Chrome-plated brass, 1/2'' x 1/4''
Manufacturer Resources
Product Specs
- Connection Type:
- P x CTS
- Material Type:
- Chrome-Plated Brass
- Product Dimension:
- 1/2'' x 1/4''
- Department:
- Plumbing
- Product Group:
- Plumbing
- Product Subgroup:
- Valves
- Product Type:
- Valve
- Product Length:
- 2.492"
- Product Height:
- 1.76"
- Product Weight:
- 0.278 lbs
- Product Width:
- 0.85"
- Product Material:
- Chrome-plated brass
Viega 93511 – Frequently Asked Questions
1) What do the 1/2 inch and 1/4 inch sizes on the Viega 93511 stop valve connect to?
The Viega 93511 angle stop is a P x CTS valve: the 1/2 inch end is a PureFlow press connection that goes onto 1/2 inch PEX with a Viega press tool, and the 1/4 inch outlet is CTS (copper tube size) compression for the riser going up to a faucet or toilet. So the inlet gets crimped, not threaded, and the outlet takes a standard 1/4 inch supply line.
2) Do I need a press tool for the Viega 93511 PureFlow angle stop, or can it be installed with a crimp ring?
It is a PureFlow Press fitting, so it needs a Viega press tool with the correct PureFlow jaw for 1/2 inch. There are no crimp rings, clamps, or threads on the inlet. If you are working off a cinch or copper crimp system, this valve will not work for you.
3) Is the Viega 93511 angle stop valve lead free for potable water?
Yes. The 93511 is a Zero Lead chrome-plated brass angle stop, which is what you need for potable water supply to lavatories, toilets, and sinks.
4) Will the Viega 93511 angle stop fit in a tight vanity or behind a toilet?
It is a compact angle body: 2.492 inches long, 1.76 inches high, and 0.85 inches wide, weighing 0.278 lbs. That footprint clears most vanity cabinets and toilet rough-ins, but measure your stub-out to finished wall before committing, since the press inlet has to be fully supported on the PEX.
5) Angle stop or straight stop for a PEX stub-out coming out of the wall?
The 93511 is the angled version, which is what you want when the 1/2 inch PEX comes horizontally out of the wall and the riser needs to turn up to the fixture. A straight stop is for supply coming vertically up through the floor. Picking the wrong orientation means kinking the riser, so match the body to how the stub-out exits.
6) Is a chrome-plated angle stop like the Viega 93511 okay for exposed installs under a sink?
That is exactly what the chrome plating is for. The body is chrome-plated brass, so it is finished to be seen under a lavatory or behind a toilet rather than buried in a wall. For concealed work you would normally use an unplated brass or bronze fitting instead.
7) Where is the Viega 93511 stop valve made?
The 93511 PureFlow press angle stop is made in Canada. That matters on public and institutional jobs with country-of-origin or trade-agreement requirements on the submittal.
