95065 Viega MegaPress 45° elbow Smart Connect technology 304 stainless steel, 1'' x 1''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2
- Material Type:
- 304 Stainless Steel
- Product Dimension:
- 1'' x 1''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Elbows
- Product Type:
- 45° Elbow
- Product Length:
- 4.386"
- Product Height:
- 1.78"
- Product Weight:
- 0.641 lbs
- Product Width:
- 3.071"
- Product Material:
- 304 stainless steel
Viega 95065 – Frequently Asked Questions
1) What size pipe does the Viega 95065 MegaPress 45 degree elbow fit?
The 95065 is a 1 inch by 1 inch fitting, so both ends press onto 1 inch pipe. Connection type is P1 x P2, meaning press on both ends rather than a threaded or grooved end. If you need to transition out of press to thread on that leg, you need a different fitting, not this one.
2) Is the Viega 95065 elbow stainless or carbon steel?
It is 304 stainless steel. That matters when you pick it: MegaPress comes in both carbon steel and stainless versions, and mixing them on the same run is a corrosion decision, not a cosmetic one. Use the 304 stainless 95065 where the system or the environment calls for stainless.
3) What is Smart Connect on the Viega MegaPress 45 degree elbow and why does an installer care?
Smart Connect is the feature built into the 95065 press elbow that lets an unpressed connection leak during pressure testing, so a joint you missed shows itself on the test instead of after the walls close. It does not change how you press the fitting; it changes how you find the one you skipped.
4) How much space does a 1 inch MegaPress 45 degree elbow take up in a tight chase?
The 95065 measures 4.386 inches in length, 3.071 inches in width and 1.78 inches in height, and weighs 0.641 lbs. Remember to allow clearance beyond the fitting body itself for the press tool jaw to seat squarely on each end, which is usually the real constraint in a chase, not the fitting.
5) Should I use a 45 degree elbow or two 90s to get around an obstruction?
A pair of 45s like the 95065 gives you a gentler offset with less directional change than stacking 90s, which keeps pressure drop down and makes the run easier to support. Use 90s when you need a hard turn at a wall or riser. Either way with MegaPress you are adding two press joints per fitting, so count your press cycles and your jaw access before choosing.
