95190 Viega MegaPress tee Smart Connect technology 304 stainless steel, 1'' x 1'' x 1/2''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2 x FPT
- Material Type:
- 304 Stainless Steel
- Product Dimension:
- 1'' x 1'' x 1/2''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 5.26"
- Product Height:
- 1.78"
- Product Weight:
- 0.862 lbs
- Product Width:
- 2.594"
- Product Material:
- 304 stainless steel
Viega 95190 – Frequently Asked Questions
1) What are the three outlets on the Viega 95190 MegaPress tee?
Two 1 inch press ends on the run and a 1/2 inch female pipe thread branch. Viega lists the connection as P1 x P2 x FPT at 1 inch x 1 inch x 1/2 inch, so you press the two larger ends onto pipe and thread into the branch.
2) Can I use the MegaPress 95190 tee to take a 1/2 inch threaded branch off a 1 inch black iron line?
That is what the fitting is built for. The 1 inch press ends go onto the existing pipe and the 1/2 inch FPT branch takes a male-threaded nipple, gauge, drop, or valve without any additional adapter. No threading or welding on the run itself.
3) Is the Viega 95190 tee stainless or carbon steel, and does that matter for what I run through it?
It is 304 stainless steel, not carbon steel. That matters because MegaPress carbon steel fittings and MegaPressG are the gas and black-iron line, while the stainless body here suits applications where you do not want a carbon steel fitting on the pipe. Match the fitting material to what the specifying engineer called out on the drawing.
4) What is Smart Connect on this Viega MegaPress tee and why do installers care?
Smart Connect is Viega's unpressed-connection feature: an unpressed joint leaks visibly during pressure test, so a missed press shows up before the walls close. On a three-outlet fitting like the 95190 that is three separate joints to account for, which is exactly where a skipped press happens.
5) Should I use a press tee with a threaded branch or an all-press reducing tee?
Pick the FPT branch version, like the 95190 at 1 x 1 x 1/2, when the takeoff lands at a threaded device, a gauge, a sensor, or a threaded valve, so you are not adding a press-by-thread adapter. Go all-press when the branch continues as pipe, since each threaded joint is one more place to dope, wrench, and leak-check.
6) What is the exact part number and origin for the Viega 1 x 1 x 1/2 stainless MegaPress tee?
Order it as Viega part number 95190. It is manufactured in Germany, which is the detail submittal packages and buy-clause reviews usually want on record.
