ABH 0327 Center Hung Pivot Set...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$233.00
$228.96
ABH ABH 0327 Pivot Set - Center Hung - Standard Duty - Up to 135 lbs ABH-0327

ABH 0327 Center Hung Pivot Set Standard Duty 135 lbs Door Weight Capacity

(No reviews yet) Write a Review

Model: 0327-US26
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$233.00
$228.96
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

ABH Center Hung Pivot Set Standard Duty 135 lbs Door Weight Capacity

Professional Center Hung Pivot System for Commercial Door Applications

The ABH Center Hung Pivot Set delivers reliable door support for commercial applications with a maximum door weight capacity of 135 lbs and door size up to 42" x 96". This non-handed pivot system centers into the door thickness for balanced operation and includes both top and bottom pivot components for complete door hanging solutions. Fire rated for 3 hours and constructed from stainless steel for long-term durability in demanding commercial environments.

Professional Features & Benefits

  • Door Weight Capacity: Supports doors up to 135 lbs with maximum door size of 42" x 96" for versatile commercial applications.
  • Center Hung Design: Pivot set centers into door thickness providing balanced weight distribution and smooth operation.
  • Non-Handed Configuration: Universal design eliminates handing requirements for simplified specification and installation.
  • Fire Rated Construction: 3-hour fire rating ensures code compliance for fire-rated door assemblies.
  • Stainless Steel Construction: Durable stainless steel substrate provides corrosion resistance and long-term reliability.
  • Complete Pivot System: Includes 0321 top pivot and 0327 bottom pivot components for comprehensive door hanging solution.
  • BAA Qualified: Meets Buy American Act requirements for government and institutional projects.

Technical Specifications

  • Application: Standard Door
  • BAA Qualified: Yes
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Door Weight: Up to 135 lbs
  • Duty Level: Standard Duty
  • Electronic: No
  • Fire Rated Time: 3 hours
  • Fire Rating: Yes
  • Hang Type: Offset Hung
  • Keyed: N/A
  • Keyed Function: N/A
  • Mounting Method: Center Hung
  • Pivot Type: Top & Bottom
  • Product Attribute: Pivots
  • Product Category: Door Hinges and Pivots
  • Product Group: Door Hinges and Pivots
  • Product Model: 180
  • Product Subgroup: Pivots and Pivot Sets
  • Product Substrate: Stainless Steel
  • Product Type: Pivot Sets - Offset
  • Subcategory: Door Pivots

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Government and Municipal Buildings
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Fire-Rated Door Assemblies

Why Choose ABH Quality?

ABH pivot systems deliver professional-grade reliability with stainless steel construction rated for 135 lbs door weight capacity and 3-hour fire rating compliance. The center hung design provides balanced operation while BAA qualification ensures suitability for government projects. Engineered for demanding commercial applications where dependable door hardware performance is essential.

Product Specs

Product Group:
Door Hinges and Pivots
Product Subgroup:
Pivots and Pivot Sets
Product Type:
Pivot Sets - Offset
Subcategory:
Door Pivots
Commercial/Residential:
Commercial
Hang Type:
Offset Hung
Keyed:
N/A
Keyed Function:
N/A
Door Weight:
Up to 135 lbs
BAA Qualified:
Yes
Duty Level:
Standard Duty
Fire Rated Time:
3 hours
Electronic:
No
Pivot Type:
Top & Bottom
Mounting Method:
Center Hung
Application:
Standard Door
Product Attribute:
Pivots
Product Model:
180
Fire Rating:
Yes
Product Category:
Door Hinges and Pivots
Product Substrate:
Stainless Steel
Department:
Door Hardware

ABH 0327-US26 – Frequently Asked Questions

1) Will the ABH 0327 center hung pivot set hold a 42 x 96 inch commercial door?
That is the ceiling for the 0327. The set is rated to a maximum door size of 42 by 96 inches and up to 135 lbs of door weight, standard duty. A 42 x 96 door right at or under 135 lbs is within rating; go heavier than 135 lbs and you need a heavy duty pivot instead, not this one.
2) Do I have to order the ABH 0327 handed, left or right?
No handing to specify. The 0327 is a non-handed center hung set, so one part number covers both swings. For a property manager stocking spares across a building, that means a single pivot set on the shelf covers every opening it fits instead of a left and a right.
3) What comes in the ABH 0327 pivot set, and can I buy just the top or just the bottom?
Three ways to order it. The full 0327 set includes the 0321 top pivot and the 0327B bottom pivot, which is what you want when hanging a new door. If you are only replacing a worn part, the 0321 top pivot and the 0327B bottom pivot are each orderable on their own. Bottom pivots take the wear on a center hung door, so 0327B alone is the common service order.
4) What is the difference between a center hung pivot and an offset pivot?
A center hung pivot like the 0327 sets the pivot point into the door thickness, so the door swings on its own centerline and can swing both ways with balanced weight distribution. An offset pivot puts the pivot point forward of the door face, which throws the door clear of the frame on opening and is what you use where a door has to swing out past a stop or where an overhead closer arm needs the offset geometry. They are not interchangeable in a prepped frame: the floor and head prep locations are different. If the existing opening is prepped offset, the Calibre Door Closers PV1000 3/4 inch offset flush pivot set or the BEST A3 System offset hung pivot set are the offset alternatives.
5) Is the ABH 0327 pivot set Buy American Act compliant for a federal job?
BAA qualified, yes. That matters if you are buying for a government, municipal, or federally funded institutional project where the spec calls out Buy American Act compliance on the hardware. The set is stainless steel construction, so it also holds up in the corrosive and high traffic conditions those buildings see.
6) What is a fire-rated alternative to the ABH 0327 pivot set for a 3-hour rated opening?
The ABH 0327 pivot set carries a fire rating with a 3 hour fire rated time, and the BEST A3 System Offset Hung Pivot Set is also fire rated, which makes it the closest peer to look at when a rated opening has to stay compliant. The difference to check before swapping is the mounting: the ABH 0327 is a center hung set with the pivot centered into the door thickness, while the BEST A3 is described as an offset hung pivot set, so the door prep and the swing geometry differ. For an institutional or government job, note that the ABH 0327 is BAA qualified.
7) Can I get the ABH 0327 pivot set in a finish that matches the rest of my door hardware?
Fourteen finishes across the 0327 range: black suede powder coat, bright brass, bright bronze, bright chrome, bright stainless steel, oil rubbed bronze, painted aluminum, painted brass, painted dark bronze, painted satin bronze, satin brass, satin bronze, satin stainless steel, and white suede powder coat. The painted and powder coat finishes are the ones people pick when the pivot has to disappear into a painted frame rather than match a lever.
8) Does the ABH 0327 pivot set take power for an electric strike or electrified lock?
No. The 0327 is a mechanical pivot set with no electrification, so it carries no power transfer through the pivot. If your opening needs power to the door leaf, that has to come from a separate power transfer device or an electrified hinge, not from this set.
9) Is the ABH 0327 pivot rated for a commercial opening or is it a residential part?
Commercial, standard duty, for a standard door application. The 135 lb rating and 3 hour fire rating put it on office, school, healthcare, and multi-tenant residential corridor doors. It is not the pivot for a heavy full glass entrance or an oversize monumental door, both of which exceed the standard duty range.
10) I am replacing an existing pivot from another brand. How do I confirm the ABH 0327 crosses over?
ABH publishes a pivots cross reference chart and a substitution request form for exactly this. Match on the physical prep first, since a center hung set has to land in the existing floor and head prep, then confirm the door weight is at or under 135 lbs so you are inside the standard duty rating. If the opening turns out to be prepped for an offset pivot rather than center hung, the 0327 is the wrong part and an offset set is what you need.
11) My floor is recessed under the door. Is there an extension for the ABH 0327 bottom pivot?
There is. ABH publishes an extension bottom spindle for the 0327, which is how you make up the gap when the finished floor sits lower than the bottom pivot expects, or when a floor covering was added after the frame went in. Take the spindle length from your actual measured floor to door bottom clearance before ordering.
12) How does the ABH 0327 compare to the BEST A3 pivot set for a standard duty commercial door?
Both are fire rated pivot sets for commercial openings. The ABH 0327 is a standard duty, non-handed center hung set in stainless steel, carrying doors up to 135 lbs with a 3 hour fire rated time, and it is supplied as a top and bottom pair in finishes from bright and satin stainless steel through bright brass, satin bronze, oil rubbed bronze, and black or white suede powder coat. The BEST A3 System is an offset hung pivot set and is also fire rated. The choice comes down to whether the opening is laid out to pivot on the door centerline or on an offset.
13) Can the ABH 0327 be set up for a non standard opening or a special layout?
Yes, through a special layout order. ABH provides a pivot and pivot sets special layout order form for openings that fall outside the standard configuration, plus pivot configuration drawings covering the center hung sets. Use those when the opening has an unusual floor condition, an out of the ordinary door thickness, or a configuration the standard set does not cover.
