ABH 4400RA Series Surface Mount Medium Duty Overhead Door Holder & Stop with Adjustable Opening Control

(No reviews yet) Write a Review

Model: ABH-4411RA-US26
$298.00
$292.84
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$298.00
$292.84
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

ABH 4400RA Series Surface Mount Medium Duty Overhead Door Holder & Stop with Adjustable Opening Control

Professional Overhead Door Control Solution

The ABH 4400RA Series delivers reliable overhead door control with surface mount installation for medium duty applications. This non-handed unit features an internal channel slide system that allows field-adjustable opening degrees from 85° to 110° in 5° increments. Designed for doors ranging from 1-3/4" to 2-1/4" thick, it provides stop, hold-open, and friction functions for both interior and exterior installations on frequent traffic and heavy weight doors.

Professional Features & Benefits

  • Adjustable Opening Control: Internal channel slide allows field adjustment from 85° to 110° opening in 5° increments for precise door positioning.
  • Door Thickness Compatibility: Standard fasteners with sex bolts accommodate doors from 1-3/4" to 2-1/4" thick with options available for other thicknesses.
  • Shock Absorbing Design: Built-in spring provides 3° to 5° cushion before dead-stop for smooth operation and reduced wear.
  • Multi-Function Operation: Combines stop, hold-open, and friction functions in a single unit for versatile door control.
  • Fire Door Compatibility: UL Listed as Miscellaneous Fire Door Accessories for wood fire doors up to 90 minutes and metal fire doors up to 3 hours (stop function only).
  • Universal Installation: Non-handed design suitable for both interior and exterior use on frequent traffic and heavy weight doors.
  • Medium Duty Construction: Engineered for commercial applications with average weight of 5 lbs per unit for reliable performance.
  • BAA Qualified: Meets Buy American Act requirements for qualifying projects and government installations.

Technical Specifications

  • BAA Qualified: Yes
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Keyed: N/A
  • Keyed Function: N/A
  • PDF:4400RA Series Surface Mount, Medium Duty Overhead Holder & Stop, Adjustable: https://zensupply.com/content/pdf/abh/0002560_4400ra_1_2_00.pdf
  • PDF:Overhead Holders/Stops - Lead Lining: https://zensupply.com/content/pdf/abh/0002593_lead_lining_option_00.pdf
  • PDF:Tech Memo: https://zensupply.com/content/pdf/abh/0002580_tm_surface_overhead_holders_stops_with_blade_stops_00.pdf
  • Product Category: Door Controls
  • Product Group: Door Controls
  • Product Model: 4400RA
  • Product Subgroup: Overhead Stops and Holders
  • Product Type: Overhead Stops and Holders - Surface Mount
  • Series: 4400RA Series
  • Subcategory: Door Stops & Holders

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose ABH Quality?

ABH 4400RA Series overhead door holders deliver professional-grade reliability with medium duty construction rated for frequent traffic and heavy weight doors. UL Listed for fire door applications up to 3 hours on metal doors and 90 minutes on wood doors, with BAA qualification for government projects. Engineered for demanding commercial applications where dependable door control and adjustable positioning are essential.

Product Specs

Product Group:
Door Controls
Series:
4400RA Series
Product Subgroup:
Overhead Stops and Holders
Product Type:
Overhead Stops and Holders - Surface Mount
Subcategory:
Door Stops & Holders
Commercial/Residential:
Commercial
Keyed:
N/A
Keyed Function:
N/A
BAA Qualified:
Yes
Product Model:
4400RA
Product Category:
Door Controls
Department:
Door Hardware

ABH ABH-4411RA-US26 – Frequently Asked Questions

1) What door thickness does the ABH 4400RA overhead stop mount to?
Standard fasteners with sex bolts on the 4400RA cover doors 1-3/4 to 2-1/4 inches thick, which takes in the usual 1-3/4 inch commercial door plus the thicker lead-lined and acoustic leaves. ABH does offer fastener options for thicknesses outside that band, so a door heavier or thinner than the standard range is still workable.
2) Can I set how far the door opens with the ABH 4400RA, or is the stop angle fixed?
It is field adjustable. An internal channel slide sets the stop point anywhere from 85 to 110 degrees in 5 degree steps, so one unit can be dialed in on site once you see what the door actually clears. A built-in spring gives 3 to 5 degrees of cushion before the dead stop, which takes the slam out of a door that gets thrown open.
3) What is the difference between the stop, hold open, and friction versions of the ABH 4400RA?
Three functions are offered on the 4400RA and you choose one when you order. Stop only arrests the door at the set angle and lets it close normally. Hold open catches and holds the door at that angle until someone pulls it free, which is what you want on a loading door or a room being aired out. Friction gives resistance through the swing so the door stays wherever you leave it rather than latching at one point, and it is the usual pick on a door in a windy exterior opening. Note that only the stop function carries the fire door listing.
4) Is a medium duty overhead stop enough, or do I need heavy duty?
The 4400RA is rated medium duty for frequent traffic and heavy weight doors, which covers most office, retail, classroom, and multi-tenant corridor openings. Where the door gets abused (industrial, exterior wind load, oversized leaves, doors people routinely swing hard into the stop), step up to a heavy duty unit. ZenSupply carries the Glynn-Johnson 90 Series and the Norton Rixson 7 Series and 9ADJ Series in heavy duty, the 9ADJ being the closest heavy duty match if you still want an adjustable 110 degree stop.
5) Do I need to specify handing when ordering an ABH 4400RA overhead stop?
No handing to specify. The 4400RA is non-handed, so one unit works on a left or right swing and it can go on interior or exterior openings. For a property manager stocking spares across a building, that means one part number per size and finish instead of two.
6) What is the closest equivalent to the ABH 4400RA from another brand?
On duty level, the Glynn-Johnson 450 Series is the other medium duty surface overhead holder and stop we carry. If the adjustable stop angle is the reason you are looking at the 4400RA, the Norton Rixson 9ADJ Checkmate is the adjustable surface mount unit with a 110 degree opening, and the Sargent 1540 is a medium duty Grade 1 surface stop/holder also at 110 degrees. Where you only need a friction stop and nothing else, the DORMA 701F standard duty friction stop covers a 21 to 27 inch door opening.
7) Does the ABH 4400RA meet Buy American requirements for a federal job?
The 4400RA is BAA qualified, so it can be specified on Buy American Act projects and government or municipal installations. That is the usual sticking point on federal and public school work, and it is one of the reasons this series shows up on those spec lists.
8) Can an overhead stop like the ABH 4400RA go on a lead lined door?
Lead lining is a documented option on ABH surface overhead holders and stops, and ABH publishes a separate lead lining instruction for that application. That matters on healthcare and imaging suite doors, where the leaf runs thicker than a standard door; the 4400RA standard fastener set covers 1-3/4 to 2-1/4 inches, with fastener options for thicknesses beyond that.
9) Do I still need a floor stop or wall stop if I install an ABH 4400RA?
No. An overhead stop like the 4400RA arrests the door at the head, so it does the job of a wall or floor stop without putting a bumper in the walking path or a mushroom in the floor. That is the reason it gets specified in corridors, hospital wings, and anywhere a floor stop becomes a trip hazard or a mop obstruction, and it also protects the closer arm by taking the impact at the frame rather than at the door edge.
10) If I only need the door to hold position by friction and not a hold open or dead stop, is there a simpler unit than the ABH 4400RA?
Yes. The ABH 4400RA combines stop, hold open, and friction into one series and is ordered by the function you need. If friction is all the opening requires, the DORMA 701F is a standard duty surface applied friction stop covering a 21 inch to 27 inch door opening, built for that single function rather than the full stop and hold open set.
11) What overhead stop should I use on an industrial door instead of the ABH 4400RA?
For industrial service, the Norton Rixson 7 Series Checkmate is an industrial duty surface door stop and holder with hold open function, rated heavy duty and Grade 1. The Sargent 590 is a heavy duty overhead surface mount door stop and holder with bronze construction, also Grade 1. The ABH 4400RA is medium duty, engineered for frequent traffic and heavy weight doors in commercial settings such as offices, schools, healthcare, and retail.
12) Is a slide track arm overhead stop the same thing as the ABH 4400RA?
They are different arm designs. The Norton Rixson 10 Series Checkmate is a surface door stop and holder with a slide track arm, heavy duty and Grade 1. The ABH 4400RA uses an internal channel slide that is field adjustable from 85 to 110 degrees in 5 degree increments, with a built in spring giving a 3 to 5 degree cushion before the dead stop. If a submittal calls out a slide track arm specifically, confirm which arm style the drawing shows before substituting.
13) I need an overhead stop for a Buy American Act project - which one qualifies?
The ABH 4400RA is BAA qualified, which matters on federal and municipal work where domestic sourcing is a condition of the contract. It is a medium duty surface mount overhead holder and stop, UL Listed as a Miscellaneous Fire Door Accessory for wood fire doors up to 90 minutes and metal fire doors up to 3 hours on the stop function. Comparable surface overhead units such as the Glynn-Johnson 450 Series and the Sargent 1540 are medium duty as well, so the deciding factor on a BAA job is the sourcing qualification rather than the duty class.
14) What finishes does the ABH 4400RA overhead holder come in to match the rest of my door hardware?
Fourteen finishes are offered: Bright Brass, Bright Bronze, Bright Chrome, Bright Stainless Steel, Oil Rubbed Bronze, Satin Brass, Satin Bronze, Satin Stainless Steel, and painted Aluminum, Black, Brass, Bronze, Dark Bronze, and White. Satin Stainless and the painted Aluminum are the two that most often match existing closers and push bars in a commercial corridor; the painted options are the ones to look at when you are matching a frame color rather than a lockset.
15) Which overhead stop matches an oil rubbed bronze or painted finish already used on the other doors?
The ABH 4400RA comes in fourteen finishes including Oil Rubbed Bronze, Satin Bronze, Bright Bronze, Satin and Bright Stainless Steel, Bright and Satin Brass, and painted options in Aluminum, Black, Brass, Bronze, Dark Bronze, and White. Among comparable overhead units, the Sargent 590 is a heavy duty surface mount stop and holder with bronze construction. If a fleet of doors is being standardized, the 4400RA finish list is the one to match against.
