Accentra 8800FL Grade 1 Classroom/Office Mortise Lock with Pinehurst Lever

(No reviews yet) Write a Review

Model: PNR-8809FL-626
From the 8800 Series Collection
$1,306.31
$778.47
Selected Finish is
Selected Rose/Escutcheon is
Selected Cylinder is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,306.31
$778.47
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Accentra 8800FL Grade 1 Classroom/Office Mortise Lock with Pinehurst Lever

Heavy-Duty Commercial Mortise Lock Solution

The Accentra 8800FL Grade 1 Mortise Lock delivers uncompromising strength and durability for commercial applications with its reinforced stainless steel deadbolt and heavy-duty vandal-resistant trim. Designed for 1-3/4" to 3-1/4" door thickness with 2-3/4" backset and 3/4" latchbolt throw, this classroom/office function lock features field reversible handing and ANSI/BHMA Grade 1 certification. UL/cUL listed for 3-hour fire rated doors with 10-year mechanical warranty for reliable commercial performance.

Professional Features & Benefits

  • Functions available for any industrial or commercial application
  • Field adjustable handing
  • Available in a variety of attractive trims and finishes
  • Status indicator options available to provide peace of mind on the locked/unlocked status of a door
  • Lever attached directly to escutcheon trim for added security (Specific to 8800 SL version)
  • Thrubolted security head screws offer added protection (Specific to 8800 SL version)
  • UL/cUL listed for 3-hour fire rated doors
  • Heavy-duty escutcheon trim for resistance against damage and vandalism
  • 10-year mechanical warranty
  • Certified ANSI/BHMA A156.13, Series 1000, Operational Grade 1 (8800FL with CN escutcheon & SL8800 meet Security Grade 1).

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness (1-3/4" to 3-1/4"), 2-3/4" backset, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Educational Facilities and Classrooms
  • Commercial Office Buildings
  • Healthcare Institutions
  • Government and Municipal Buildings
  • Multi-Tenant Residential Properties
  • Industrial and Warehouse Facilities
  • Retail Establishments

Why Choose Accentra Quality?

Accentra 8800 Series mortise locks deliver professional-grade reliability with reinforced stainless steel deadbolt construction and heavy-duty vandal-resistant trim rated for ANSI/BHMA Grade 1 performance. Backed by a comprehensive 10-year mechanical warranty and UL/cUL listing for 3-hour fire rated doors, this lock provides the dependable security and durability essential for demanding commercial applications.

Product Specs

Series:
8800 Series
Subcategory:
Lever Locksets
Keyed Function:
Single Cylinder
Grade:
Grade 1
Product Group:
Mechanical Locks
Product Subgroup:
Mortise Locks and Trim
Product Type:
Mortise Lock
Keyed:
Yes
Commercial/Residential:
Commercial
Handle Type:
Lever
Lock Function:
Classroom/Office
Product Attribute:
Mortise Locks
Electronic:
No
Product Model:
8808
Collection:
8800 Series
Product Function:
Classroom/Office
Lever Design Name:
Pinehurst Lever
Product Category:
Mechanical Locks
Department:
Door Hardware

Accentra PNR-8809FL-626 – Frequently Asked Questions

1) Do I have to order the Accentra 8800FL handed?
No. Handing is field adjustable on the 8800FL, so one lock covers left and right hand openings. That matters for a property manager stocking spares: a single part number covers every door in the building rather than two.
2) What does the classroom/office function on the Accentra 8800FL actually do?
Classroom/office means the outside lever is locked and unlocked by key from the outside, and the inside lever always retracts the latch for free egress. It is a single cylinder, keyed lock, so there is no key requirement on the inside. Use it where staff control the door but occupants must always be able to get out.
3) Can the Accentra 8800FL go on a 3-hour fire rated door?
Yes. The 8800FL is UL and cUL listed for use on 3-hour fire rated door assemblies, and its 3/4 inch latchbolt throw is the standard positive latching throw a fire door needs. It is also certified to ANSI/BHMA A156.13, Series 1000, Operational Grade 1.
4) What is the difference between the CN escutcheon and the rose trim on the Accentra 8800FL?
Both trims are offered with the Pinehurst lever, but they are not equivalent on security. The 8800FL with the CN escutcheon meets ANSI/BHMA Security Grade 1; the rose version carries the Operational Grade 1 certification. The escutcheon is heavy-duty and vandal resistant, which is the usual choice for schools, dorms and other abused openings. Rose trim is the lighter-looking option for offices.
5) Can I order the Accentra 8800FL without a cylinder so I can use my own keyway?
Yes. A less cylinder option is offered on both the escutcheon and rose versions, which is how you spec it when the building is keyed to an existing master system and you will supply your own mortise cylinder. If you do not have a system to match, the factory option ships with a conventional cylinder in the PARA-E1R keyway.
6) What is a comparable Grade 1 classroom mortise lock to the Accentra 8800FL with Pinehurst lever?
The Corbin Russwin ML2003 is the closest straight equivalent - a Grade 1 mortise classroom lockset in the ML2000 Series, listed for 1-3/4 inch doors. The Accentra 8800FL is a Grade 1 classroom/office mortise lock that covers a wider 1-3/4 inch to 3-1/4 inch door thickness range with a 2-3/4 inch backset, so on thicker doors the 8800FL is the one that stays in range. Cal-Royal's NM8070 is another Grade 1 classroom mortise lockset with an auxiliary deadlatch, also specified for 1-3/4 inch doors.
7) If the opening does not need a key, what mortise lock should I use instead of the Accentra 8800FL?
The 8800FL is a keyed single-cylinder classroom/office lock, so for a non-keyed opening look at a passage or office function body instead. The Hager 3810E is a Grade 1 passage mortise lock with escutcheon trim and a 2-3/4 inch backset for 1-3/4 to 2-1/2 inch doors, and the 3810S is the same function with rose trim. The Hager 3850E is a non-keyed office function mortise lock with lever and escutcheon on the same 2-3/4 inch backset. Falcon's MA101 is a Grade 1 heavy duty mortise passage lock with field reversible operation and a fire rating, matching the 8800FL's field reversible handing.
8) I need the outside lever always locked rather than classroom function - what mortise lock covers that?
The Accentra 8800FL is a classroom/office function. For a storeroom opening where the outside lever stays locked, the Cal-Royal NM8080 is a Grade 1 storeroom mortise lockset for 1-3/4 inch doors with an interchangeable core option. For an entrance/office opening, the Cal-Royal NM8050 is the Grade 1 entrance/office version with auxiliary deadlatch. Sargent's 7925 is a Grade 1 heavy duty corridor/dormitory function mortise lock with rose trim and a single cylinder deadbolt.
9) Is the Accentra 8800FL an electronic lock, and what should I look at if I want keypad or credential access instead?
No, the 8800FL is entirely mechanical and key operated. For credential or code access on a mortise prep, the TownSteel FME-2000 is a Grade 1 classroom mortise lockset with RFID for 1-3/4 inch doors, the Alarm Lock DL3500CR is a Grade 1 electronic classroom mortise lock for 1-5/8 to 1-7/8 inch doors, and the Schlage LEMD-GRW is a Grade 1 ENGAGE wireless mortise lock with a 125kHz proximity reader.
10) Can I tell from the hallway whether an 8800 Series door is locked?
Status indicator options are offered in the 8800 Series to show locked or unlocked state at the door, which is what most school districts now want on classroom openings. If an indicator is a hard requirement on your spec, the Marks USA LA318GJ is a Grade 1 classroom security indicator mortise lockset with an ANSI strike and steel escutcheon for 1-3/4 inch doors.
11) Will the 3/4 inch latchbolt on the Accentra 8800FL work with my existing ANSI strike?
A 3/4 inch latchbolt throw is the standard commercial mortise projection, so it lands in a standard ANSI 4-7/8 inch strike with no frame change, provided the existing prep is a true mortise pocket on a 2-3/4 inch backset. If the door currently carries a cylindrical lockset, the door has to be re-prepped for a mortise case.
12) Is the Accentra 8800FL heavy duty enough for a high traffic school corridor?
It is built for exactly that. The 8800FL carries ANSI/BHMA Grade 1 certification, uses a reinforced stainless steel deadbolt, and the escutcheon trim is heavy duty and vandal resistant. It is specified as commercial hardware, not residential, and the same lock covers classrooms, dorm corridors, healthcare and municipal buildings so a facility can standardise on one lock body.
13) What looks like a substitute for the Accentra 8800FL but will not work on a commercial classroom door?
Watch for three types. Dummy trims such as the Schlage L0170 half dummy and the Emtek 3102 Memphis and 3104 Hamilton mortise entrance dummies have no latch or keyed function at all. Deadbolt-only bodies such as the Sargent 4874 double cylinder mortise deadbolt on a 2-3/4 inch backset and the Kaba Ilco 185 Series deadbolt provide no lever operation. And residential-scale bodies such as the Baldwin 6301 entry/apartment lever-by-lever use a 2-1/2 inch backset, not the 2-3/4 inch backset the 8800FL is prepped for.
14) We need access control on the same doors as our Accentra 8800FL locks - what mortise lock integrates with a system?
For wired electric operation, the BEST 45HW is a heavy duty wired electromechanical mortise lock running 12V or 24V, and the Command Access ML190 is a heavy duty motorized mortise lock with field selectable fail-safe/fail-secure operation at 24VDC in storeroom function. The Schlage L9092EU with 03A trim is a heavy duty corridor function mortise lock, keyed outside, with request to exit and 12/24VDC operation for 1-3/4 inch doors. For wireless, the Schlage LEMD-GRW is a Grade 1 ENGAGE Series wireless mortise lock with a 125kHz proximity reader and a 3-hour fire rating. The 8800FL itself is mechanical only.
15) What finish does the Accentra 8800FL Pinehurst lever come in?
626 satin chrome, across every trim and cylinder combination. That is the standard commercial finish, so it will match most existing lever hardware, closers and exit device trim already installed in schools, offices and multi-family corridors.
16) For a keyless classroom door without wiring, what works instead of the Accentra 8800FL?
Standalone pushbutton mortise locks avoid both keys and wiring runs. The Dormakaba E-Plex 2066 is an electronic pushbutton keyless mortise lock for wide stile applications, and the PowerPlex P2066 is a mortise lock in the PowerPlex 2000 Series. The Dormakaba E5086 is a Grade 1 back-to-back pushbutton and card entry/egress mortise lock. The Accentra 8800FL is the mechanical keyed route on the same opening, with a 2-3/4 inch backset and 1-3/4 to 3-1/4 inch door range.
17) Is there a cylindrical alternative if the door is not prepped for a mortise pocket like the Accentra 8800FL needs?
Yes. The 8800FL requires a mortise pocket with a 2-3/4 inch backset. If the door is bored for a cylindrical lock instead, the Schlage PC10 is a Grade 1 non-keyed passage cylindrical lock with rose for 1-3/4 inch doors. If the pocket exists but only a latch is needed, the Schlage PM010 is a Grade 1 non-keyed passage latch mortise lock for 1-3/4 inch doors.
