Adams Rite 2101-02-121 Standard Radius Strike with Dustbox for 2190 Dual Force Deadbolt/Deadlatch

Adams Rite 2101-02-121 Standard Radius Strike with Dustbox for 2190 Dual Force Deadbolt/Deadlatch

(No reviews yet) Write a Review

Model: 2101-01 630
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$54.99
$34.63
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Adams Rite 2101-02-121 Standard Radius Strike with Dustbox for 2190 Dual Force Deadbolt/Deadlatch

Professional Strike Plate Component for Dual Force Systems

The Adams Rite 2101-02-121 is a standard radius strike with dustbox specifically designed for use with Adams Rite 2190 Dual Force interconnected deadbolt/deadlatch systems. This precision-engineered strike component features a radius profile for optimal alignment and includes an integrated dustbox for enhanced durability and debris protection. Available in dark bronze finish, this strike ensures reliable operation and proper integration with 2190 Dual Force hardware systems.

Professional Features & Benefits

  • Combined deadbolt and deadlatch in one lock body
  • Panic-proof single-motion exit: one interior lever retracts both bolt and latch
  • Exterior lever retracts latch only
  • Field-selectable interconnect feature
  • Accepts standard MS® cam mortise cylinder from either or both sides
  • 1" stainless steel deadbolt throw
  • 5/8" solid brass latchbolt
  • Easily reversible latchbolt (screwdriver only)
  • Stainless steel auxiliary deadlatch pin
  • Electrified trim set option (12/24 VDC)
  • Available with thick door kits

Technical Specifications

  • Door Application: Narrow stile aluminum (2190), Wood or steel stile-and-rail (2290)
  • Backset: 1-1/8" [28.6 mm] or 1-1/2" [38.1 mm]
  • Min. Door Thickness: 1-3/4" [44.5 mm]
  • Deadbolt: 1" [25.4 mm] throw, stainless steel
  • Latchbolt: 5/8" throw, solid brass
  • Faceplate: 1" × 6-7/8" [25.4 mm × 174.6 mm]
  • Voltage (electrified): 12/24 VDC continuous duty
  • Finishes: US3, US4, US10B, US32, US32D

Installation & Operation

This strike component is designed for use with compatible Adams Rite 2190 Dual Force deadbolt/deadlatch systems. Refer to the parent device installation instructions and manufacturer documentation for proper integration. Ensure compatibility with existing hardware before installation.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Adams Rite Quality?

Adams Rite strike components deliver professional-grade reliability with precision manufacturing designed for demanding commercial applications. The integrated dustbox design and radius profile ensure optimal performance with 2190 Dual Force systems. Engineered for demanding commercial applications where dependable hardware integration is essential.

Manufacturer Resources

Adams Rite Product Catalog

Product Specs

Product Group:
Parts and Accessories
Product Category:
Parts and Accessories
Department:
Door Hardware
Commercial/Residential:
Commercial
Product Subgroup:
Parts and Accessories
Product Type:
Parts and Accessories

Adams Rite 2101-01 630 – Frequently Asked Questions

1) What does the Adams Rite 2101 strike actually do, and is it the lock or just the plate?
The 2101 is the strike side only, the plate the bolt and latch throw into, with a dustbox behind it to catch debris and give the bolt a clean pocket. It is not the lock. It is made to receive the Adams Rite 2190 Dual Force interconnected deadbolt/deadlatch, which throws a 1 inch stainless deadbolt and a 5/8 inch brass latchbolt. If you are replacing the locking hardware itself, you need the 2190 lock body; the 2101 is what you order to prep or repair the jamb side.
2) Do I order the flat strike or the radius strike for my Adams Rite 2190 jamb?
Both are offered with the dust box, and the choice is decided by the jamb, not the lock. Radius With Dust Box matches a jamb pocket cut with rounded ends, the profile a router bit leaves. Flat With Dust Box is the square-cornered version. Pull the old strike and look at the cutout: rounded ends take the radius, square corners take the flat. Getting it backwards means either a gap at the ends or filing the frame.
3) Will an Adams Rite 2101 strike work on my aluminum storefront door frame?
Yes, that is the intended opening. The 2190 Dual Force lock this strike serves is built for narrow stile aluminum doors, and the 2101 is the mating jamb component for that system. On a wood or steel stile-and-rail door you are running the 2290 version of the lock instead, so confirm which of the two you have before ordering the strike.
4) Is this Adams Rite strike an electric strike, and will it work with my 12/24 VDC access control?
No, the 2101 is a mechanical strike plate with a dustbox. It has no solenoid and no wiring. The 12/24 VDC continuous duty option on the 2190 system is an electrified trim set on the door leaf, which controls the lever, not the jamb side. If you need the jamb to release electrically, you are looking for an electric strike, which this is not.
5) What strike should I use on a commercial opening that takes a standard ASA lip strike prep instead of Adams Rite 2190 hardware?
The Adams Rite 2101-02-121 is a standard radius strike with dustbox built specifically to receive the bolt and latch of an Adams Rite 2190 Dual Force interconnected deadbolt/deadlatch, so its cutout and dustbox follow that lock. For an opening prepped to the standard ASA template rather than to 2190 Dual Force hardware, the Cal-Royal ASA478 is a template ASA strike for commercial door hardware. Match the strike to the prep already in the frame: the 2101 goes with 2190 Dual Force, the ASA478 goes with an ASA-prepped frame.
6) Can an Adams Rite 2101 radius strike be used on an all-glass door?
No. The Adams Rite 2101-02-121 radius strike with dustbox is made for use with Adams Rite 2190 Dual Force deadbolt/deadlatch systems, whose minimum door thickness is 1-3/4 inch and whose application is narrow stile aluminum or wood and steel stile-and-rail doors. For a glass door, the strike has to come from the glass door lock family: the Codelocks CL4000-RSB is a glass door strike box suitable for use with CL4000 or CL4500 glass door locks.
7) What finishes does the Adams Rite 2101 strike come in, and will it match my existing storefront hardware?
Three: 119 Black Anodized, 121 Dark Bronze Anodized, and 630 Satin Stainless Steel. Those are the anodized storefront finishes, so a dark bronze frame takes the 121 and a clear or brushed aluminum opening usually pairs with the 630. All three are offered in both the flat and the radius strike, so the finish choice does not limit which profile you can order.
8) How deep does the jamb pocket need to be for a 2190 Dual Force strike?
The deadbolt on the 2190 throws 1 inch, so the dustbox has to accept a full 1 inch of bolt plus the 5/8 inch latchbolt beside it. The dustbox is what makes that work on a hollow aluminum jamb: it lines the cutout so the bolt is not throwing into raw tube. If your frame is a filled or reinforced jamb, verify there is clear cavity behind the strike cutout to seat the box.
9) Does the backset of my 2190 lock change which strike I need?
No. The 2190 is offered in 1-1/8 inch and 1-1/2 inch backsets, but backset sets how far the cylinder and bolt sit from the stile edge on the door leaf. The strike lives in the jamb and is located off the bolt centerline, not the backset. What does matter for the strike is the jamb cutout profile, flat or radius, and the finish.
10) I have a hollow metal or wood door, not aluminum. Can I use this Adams Rite strike?
Not for a standard ASA prep. The 2101 is cut for the Adams Rite 2190 narrow stile system and its dustbox geometry. A hollow metal frame with the usual ASA lock prep takes an ASA template strike instead, such as the Cal-Royal ASA478 template ASA strike. Match the strike to the prep already in the frame, not to the door material alone.
11) What is the minimum door thickness for the Adams Rite 2190 Dual Force system this strike goes with?
1-3/4 inches is the minimum, which is standard commercial door thickness. If you are working a thicker door, the 2190 is offered with thick door kits. The strike itself is unaffected by door thickness, but if the lock is not the right thickness configuration the bolt will not land in the dustbox correctly.
12) I am standardizing storefront doors across a property. Can I order the same 2190 strike for every opening?
Only if the jamb preps match. Across a building you will typically find both square and rounded strike cutouts depending on who installed what, so survey the openings and split the order between Flat With Dust Box and Radius With Dust Box. Finish can be standardized more easily: all three finishes, black anodized, dark bronze anodized, and satin stainless, are offered in both profiles.
13) Is a Securitron AOS offset strike an alternative to the Adams Rite 2101 strike?
They are different classes of part and do not substitute for each other. The Adams Rite 2101-02-121 is a mechanical strike with dustbox that receives the 1 inch stainless steel deadbolt and 5/8 inch brass latchbolt of a 2190 Dual Force lock. The Securitron AOS is a line of armature offset strikes, and the ABH 20020 is a standard door armature head assembly with 1-5/8 inch projection; both are armature-side components for magnetic locking, where nothing physically enters a bolt pocket. If the door is held by a maglock, an armature part is what mounts to the door leaf; if it is held by a 2190 Dual Force bolt, the 2101 strike is the frame-side part.
14) What is a simpler strike option for a door that only needs to be held closed, not locked?
The Adams Rite 2101-02-121 strike with dustbox exists to receive a locking bolt, since the 2190 Dual Force it serves combines a deadbolt and a deadlatch in one body with a panic-proof single-motion exit. On a door that only needs to stay shut against a light push, a roller latch and its strike do the job with no bolt at all: the ABH 1890 Series pairs a roller latch with a full lip cast strike and 5/16 inch adjustable projection, and the ABH 1895 Series pairs a roller latch with a T strike and 1/2 inch adjustable projection. The adjustable projection lets the holding force be tuned in the field, which a fixed bolt pocket cannot do.
15) Does the handing of my door change which 2190 strike I order?
No. The 2101 strike is not handed. Handing is handled at the lock, where the 2190 latchbolt reverses in the field with a screwdriver. Order the strike on jamb profile and finish, and reverse the latch on the lock body to suit the swing.
16) Will a Trimco 1268 anchor plate work in place of an Adams Rite strike?
No. The Trimco 1268 is a 3-1/2 inch diameter anchor plate, a flat mounting plate with no bolt pocket. The Adams Rite 2101-02-121 is a strike with an integrated dustbox that receives and shields the projecting bolt of a 2190 Dual Force deadbolt/deadlatch. An anchor plate gives a surface-mounted device something to fasten to; it will not accept a 1 inch deadbolt throw.
17) I need the strike in satin stainless to match the rest of the frame hardware - does the Adams Rite come that way or do I need another brand?
It comes that way. The Adams Rite 2101 strike with dust box is offered in 119 black anodized, 121 dark bronze anodized, and 630 satin stainless steel, in both the flat and the radius strike configuration, so the frame-side part can be matched to the rest of the opening without switching to a different manufacturer's strike and a different bolt pocket.
