Adams Rite 2190 Dual Force Interconnected Deadbolt/Deadlatch Lock

Adams Rite 2190 Dual Force Interconnected Deadbolt/Deadlatch Lock

Professional Dual-Function Security Solution

The Adams Rite 2190 Dual Force Interconnected Lock combines deadlatch and deadbolt capabilities in a single unit designed for narrow stile aluminum doors. This professional-grade lock features 1" deadbolt throw of stainless steel and 5/8" latchbolt throw of solid brass, with field-selectable interconnection for single-motion panic-proof exiting. The lock accepts standard 1" length mortise cylinders and includes a specially designed strike plate for proper operation.

Professional Features & Benefits

• Combined deadbolt and deadlatch in one lock body
• Panic-proof single-motion exit: one interior lever retracts both bolt and latch
• Exterior lever retracts latch only
• Field-selectable interconnect feature
• Accepts standard MS® cam mortise cylinder from either or both sides
• 1" stainless steel deadbolt throw
• 5/8" solid brass latchbolt
• Easily reversible latchbolt (screwdriver only)
• Stainless steel auxiliary deadlatch pin
• Electrified trim set option (12/24 VDC)
• Available with thick door kits

Technical Specifications

• Door Application: Narrow stile aluminum (2190), Wood or steel stile-and-rail (2290)
• Backset: 1-1/8" [28.6 mm] or 1-1/2" [38.1 mm]
• Min. Door Thickness: 1-3/4" [44.5 mm]
• Deadbolt: 1" [25.4 mm] throw, stainless steel
• Latchbolt: 5/8" throw, solid brass
• Faceplate: 1" × 6-7/8" [25.4 mm × 174.6 mm]
• Voltage (electrified): 12/24 VDC continuous duty
• Finishes: US3, US4, US10B, US32, US32D

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including 1-3/4" minimum door thickness and narrow stile aluminum door compatibility.
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces for the 1-1/8" or 1-1/2" backset configuration.
3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions for the specially designed strike plate system.
4. Install all mounting hardware and secure the lock to door and frame per manufacturer torque specifications, ensuring proper alignment of the 2101-01 strike.
5. Configure field-selectable interconnection feature as required for application and verify cylinder operation from both sides if dual-cylinder configuration is specified.
6. Test device operation including deadbolt projection/retraction, latch holdback feature, and panic-proof exiting function. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Commercial Office Buildings
• Educational Facilities
• Healthcare Institutions
• Retail Establishments
• Industrial and Warehouse Facilities
• Multi-Tenant Residential Properties
• Government and Municipal Buildings

Why Choose Adams Rite Quality?

Adams Rite Dual Force locks deliver professional-grade reliability with stainless steel deadbolt construction and solid brass latchbolt components engineered for demanding commercial applications. The field-selectable interconnection feature and electrification options provide flexibility for various security and code compliance requirements. Engineered for demanding commercial applications where dependable dual-function security performance is essential.
