AC Series 2-Door Expander Board
The AC-2DE is a two-door expander board. Up to three AC-2DE modules can be added to an ACS-2DR starter kit for a max capacity of eight doors.
The expander board has two card reader inputs, six digital inputs, four solid state dry contact relays, and two integrated lock power outputs. Communicating via RS485, this controller can be connected via AC-STRIP or standard RS485 wiring.
Advanced hardware functions include built-in ADA opener sequencing, key-switch level alarm integration, mantrap/interlock support, triple swipe actions, user specific actions, and local/remote lockdown.
FEATURES
- Two card reader inputs
- Two integrated power outputs (12V DC,500mA)
- Six digital inputs
- Key-switch level alarm integration
- Built-in ADA opener sequencing
- UL and ULC listed (UL 294/ULC S319-05)
SPECIFICATIONS
- Power Source: 12V DC (drawn from main board)
- Lock/Option Power: 12V DC 500mA
- Contact Rating: 30V DC @1A
- Dimensions: 3-1/2" x 3-3/4"
Manufacturer Resources
General Line Catalog (Full Catalog)
Product Specs
- Product Type:
- Expansion Boards & Modules
- Product Group:
- Electronic Access Controls
- Product Subgroup:
- Readers, Keypads and Credentials
- Subcategory:
- Accessories
- Commercial/Residential:
- Commercial
- Electronic:
- Yes
- Series:
- AC Series
- Product Category:
- Electronic Access Controls
- Department:
- Door Hardware
Aiphone AC-2DE – Frequently Asked Questions
1) How many doors can I add to an Aiphone AC Series system with AC-2DE expander boards?
Each AC-2DE adds two doors, and up to three of them can be added to an ACS-2DR starter kit. That takes a system to a maximum of eight doors. If your project needs more openings than that, you are into a second controller set rather than more expanders.
2) Does the AC-2DE expander board need its own power supply?
No separate supply for the board itself. The AC-2DE draws its 12V DC operating power from the main board. It does carry two integrated lock power outputs rated 12V DC at 500mA, so if your locks pull more than 500mA each you will need a dedicated lock power supply for them.
3) How is the Aiphone AC-2DE wired back to the main controller?
It communicates over RS485. You can run it on Aiphone's AC-STRIP or on standard RS485 cable, so an existing RS485 backbone in the building works without special interface hardware.
4) What inputs and relay outputs does the AC-2DE 2-door expander give me per board?
Two card reader inputs, six digital inputs, four solid state dry contact relays, and two integrated lock power outputs. The relay contacts are rated 30V DC at 1A, so higher-current or AC-switched loads need an interposing relay.
5) Is the Aiphone AC-2DE listed for use in a commercial access control installation?
It is UL and ULC listed to UL 294 and ULC S319-05, and it is a commercial-rated product. Those are the listings a spec or an AHJ typically asks for on access control equipment.
6) Can the AC-2DE handle an ADA automatic door operator and a mantrap?
Yes on both. Built-in ADA opener sequencing is a hardware function on the board, so the unlock and operator trigger sequence is handled without a separate timer module. Mantrap/interlock support is also built in, along with key-switch level alarm integration, triple swipe actions, user specific actions, and local or remote lockdown.
7) Is the AC-2DE a standalone door controller or does it require a starter kit?
It is an expander, not a standalone system. The AC-2DE has to be added to an ACS-2DR starter kit, which supplies the main board it draws power and RS485 communication from. Ordering expanders alone will not give you a working system.
8) Will the Aiphone AC-2DE board fit in my existing enclosure?
The board measures 3-1/2 by 3-3/4 inches. That is the footprint to check against the spare standoff pattern and free space inside your access control can before you order additional expanders.
