AC NIO License
AC Nio is management software for the AC Series access control system. It is used to program a system and manage everyday functionality. There are two license options available to accommodate different applications.
The Essential license can manage a system of up to 40 doors and cameras. It can be installed on a local server PC or on the AC-HOST embedded server.
The Small Business license can manage up to 80 doors and cameras, as well as elevators and unmanaged doors. This license allows up to five partitions and supports Lightweight Directory Access Protocol (LDAP) integration.
Both the AC Nio Essential and Small Business license are available in a 1- or 5-year renewal schedule.
FEATURES
If you need a larger system capacity with more doors and cameras, contact your local rep, we’re here to assist.
SPECIFICATIONS
- Operating System: Windows® 7 Professional, Windows® 7 Enterprise, Windows® 7 Ultimate or later
- CPU: 32 bit (x86) processor or 64 bit (x64) processor, 2 GHz or faster
- Memory: 4 GB or higher
- Required Storage: 1 GB (additional space required for database)
- Runtime: .NET Framework 4.5 or later
- SQL Server: Microsoft SQL Server 2008 or SQL Server 2008 Express or higher
Manufacturer Resources
General Line Catalog (Full Catalog)
Product Specs
- Product Type:
- Software & Licenses
- Product Group:
- Electronic Access Controls
- Product Subgroup:
- Readers, Keypads and Credentials
- Subcategory:
- Accessories
- Commercial/Residential:
- Commercial
- Electronic:
- Yes
- Series:
- AC Series
- Product Category:
- Electronic Access Controls
- Department:
- Door Hardware
Aiphone AC-NIO-ESS1 – Frequently Asked Questions
1) How many doors can the Aiphone AC Nio Essential license handle?
The Essential license manages an AC Series access control system of up to 40 doors and cameras. If the site is bigger than that, step up to the AC Nio Small Business license, which goes to 80 doors and cameras and also covers elevators and unmanaged doors.
2) What is the difference between the AC Nio Essential and Small Business licenses?
Capacity and features. Essential tops out at 40 doors and cameras. Small Business doubles that to 80, adds elevator control and unmanaged doors, allows up to five partitions, and supports LDAP integration. If you don't need partitioning or directory integration and the site is under 40 openings, Essential covers it.
3) Do I need a separate server PC to run AC Nio Essential, or can it run on the AC-HOST?
Either way works. The Essential license can be installed on a local server PC or directly on the AC-HOST embedded server, so a small site can skip the dedicated PC entirely.
4) Is the AC Nio Essential license a one-time purchase or does it renew?
It's a term license. The Essential license is ordered on a 1-year or 5-year renewal schedule, sold as AC-NIO-ESS1 for one year and AC-NIO-ESS5 for five years. Pick the term when you order.
5) What are the PC requirements for AC Nio management software?
Windows 7 Professional, Enterprise or Ultimate or later, a 32-bit (x86) or 64-bit (x64) processor at 2 GHz or faster, 4 GB or more of memory, and 1 GB of storage plus additional space for the database. It also needs .NET Framework 4.5 or later and Microsoft SQL Server 2008 or SQL Server 2008 Express or higher.
6) What does AC Nio actually do for an access control system?
AC Nio is the management software for the Aiphone AC Series. It's what you use to program the system in the first place and then run it day to day, managing doors, cameras and credentials. Without a license the AC Series hardware has nothing to program it.
7) Does AC Nio Essential support multiple partitions for separate tenants or departments?
No. Partitioning is a Small Business license feature, which allows up to five partitions along with LDAP integration. If you need to segment a building by tenant or department, or tie user records to a directory, Essential won't do it.
8) Can AC Nio Essential control elevators?
No. Elevator control and unmanaged doors are covered by the Small Business license, not Essential. Essential is limited to managed doors and cameras, up to 40 of them.
9) Is the Aiphone AC Nio Essential license meant for commercial buildings?
Yes, it's a commercial access control product. It runs the AC Series system in offices, multi-tenant and institutional buildings, sized for sites of 40 doors and cameras or fewer.
