AC-PF-H26 - Series 26-bit HID Format Proximity Key Fob with Brass Ring

AC Series Proximity Key Fob with brass ring is designed to work with the AC-PROX-C proximity reader.

The AC-PF-H26 Proximity Key Fob comes in HID 26-bit format.

FEATURES

  • ABS Key Fob
  • HID 26-bit format
  • Frequency 125kHz
  • Site code and card number printed on credential

SPECIFICATIONS

  • Format: Aiphone 26-bit
  • Frequency: 125kHz
  • Material: ABS
  • Dimensions: 1-1/2" H x 1-3/16" W x 1/8" D

SPECIFICATIONS

Spec Sheet

Product Specs

Product Type:
Key Fob
Product Group:
Electronic Access Controls
Product Subgroup:
Readers, Keypads and Credentials
Subcategory:
Accessories
Commercial/Residential:
Commercial
Electronic:
Yes
Series:
AC Series
Product Category:
Electronic Access Controls
Department:
Door Hardware

Aiphone AC-PF-H26 – Frequently Asked Questions

1) Will the Aiphone AC-PF-H26 key fob work with my Aiphone proximity reader?
The AC-PF-H26 is built for the Aiphone AC-PROX-C proximity reader. It reads at 125kHz in HID 26-bit format, so the reader it presents to has to be set up for that format. If your opening runs a different Aiphone reader or a different bit format, this fob is not the credential for it.
2) Is the AC-PF-H26 fob 26-bit HID format, and does that matter for my access control panel?
Format is HID 26-bit at 125kHz. That matters because a credential only reads if the panel and reader are configured for the same bit format. 26-bit is the common proximity format, so a system already running 26-bit proximity credentials will take these without a format change. A system programmed for a different bit length will reject them.
3) How do I enroll Aiphone AC-PF-H26 fobs without holding each one up to the reader?
Site code and card number are printed on each credential, so you can enroll them into the system by reading the numbers off the fob instead of presenting every one. For a property manager handing out fobs across a building, that also means you can log which number went to which tenant and void a single lost fob without re-badging everyone.
4) How big is the Aiphone AC-PF-H26 fob and will it fit on a tenant keyring?
It measures 1-1/2 inches H x 1-3/16 inches W x 1/8 inches D and comes with a brass ring already fitted, so it goes straight onto a keyring or lanyard with no extra hardware. The body is ABS plastic.
5) Should I order proximity fobs or prox cards for my building's access control?
A fob like the AC-PF-H26 is the right pick when the credential lives on a keyring: at 1-1/2 x 1-3/16 x 1/8 inches with a brass ring, it is a keychain item, and the molded ABS body takes pocket and door-frame abuse better than a thin card. Cards are the choice when you need a photo ID or a slot badge holder. Both read the same way at the reader, so the decision is about how your people carry them, not about the electronics.
6) Do I need to order anything else with Aiphone AC-PF-H26 fobs to get tenants through the door?
The fob itself is the whole credential, brass ring included. What it needs on the door side is the AC-PROX-C proximity reader, wired into your Aiphone AC Series access control. If the reader is already installed and running 26-bit, you are just adding fobs.
7) Is the Aiphone AC-PF-H26 proximity fob suitable for commercial multi-tenant use?
It is a commercial-duty credential, and the practical reason it works in multi-tenant buildings is that each fob carries its own printed site code and card number. Issue, track, and revoke per unit; nothing about the fob needs programming at the door. There is no battery in it, so a fob handed out today keeps working until it is lost or deleted from the system.
