FEATURES
- Extends wiring distance from door stations to master stations up to max. 820′
SPECIFICATIONS
- Capacity: One adaptor unit for each video door station located beyond the standard specified wire distance
- Mounting: DIN rail (included)
- Wire Type: 2-cond., low cap, PE, solid, non-shielded - use Aiphone #851602 or #851602DB (direct burial)
- Distance
- Adaptor to Door Station: 820'
- Adaptor to Master Station: 165'
Manufacturer Resources
Video Door Entry 1-2 system (JO/JV Series) Brochure
Product Specs
- Product Type:
- Adaptors
- Series:
- JF Series
- Subcategory:
- Accessories
- Commercial/Residential:
- Commercial
- Product Group:
- Parts and Accessories
- Product Subgroup:
- Parts and Accessories
- Product Category:
- Door Trim and Accessories
- Department:
- Door Hardware
Aiphone JBW-BA – Frequently Asked Questions
1) How far can the Aiphone JBW-BA run wire between a door station and the master station?
The JBW-BA long distance adaptor allows up to 820 feet from the adaptor to the video door station, plus up to 165 feet from the adaptor back to the master station. That is the total wiring reach you get when the run exceeds the standard JF Series distance.
2) Do I need one JBW-BA per door station or just one for the whole system?
One adaptor unit is required for each video door station that sits beyond the standard specified wire distance. If you have three remote entrances on a long run, that is three JBW-BA units, not one shared unit.
3) What wire does the Aiphone JBW-BA long distance adaptor require?
Use 2-conductor, low capacitance, polyethylene, solid, non-shielded cable. Aiphone specifies #851602, or #851602DB for direct burial runs. Substituting shielded or stranded station wire is not what the adaptor is rated on, and cable capacitance is what limits distance on these video runs.
4) How does the JBW-BA mount in an equipment closet or enclosure?
It mounts on DIN rail, and the rail is included with the adaptor. Plan a spot in the panel or enclosure near the master station wiring, since the adaptor has to sit within 165 feet of the master.
5) Which Aiphone system is the JBW-BA adaptor for?
The JBW-BA is the long distance adaptor for the Aiphone JF Series video intercom, used to stretch door station wiring beyond the system's standard limit. It is specified as commercial-grade equipment.
6) Does the JBW-BA work with audio-only door stations?
Capacity is stated per video door station: one adaptor for each video door station beyond the standard wire distance. That is the application Aiphone specifies for it on the JF Series.
