Aiphone NHX-30G - 30-Call Add-On Selector

(No reviews yet) Write a Review

Model: NHX-30G

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,262.00
$1,045.52
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

The NHX-30G 30-Station Add-on Selector expands the CommuniCare system to its maximum capacity of 80 stations. With a simple connection to the NHX-50M, the 80-call master station remains streamline and compact in size.

The NHR-30K Expansion Trunk Card provides the additional call signaling and control functions for the add-on selector, and is installed inside the Central Control Unit

FEATURES
  • Controlled from NHX-50M
  • Compact slimline design
  • Routine Call and Bathroom Call annunciated by slow or fast flashing LED and tone
  • Auto-connect to next call in priority -- No need to select station
  • Additional capacity controlled by NHR-30K Expansion Card (Installed in NHX-80X CCU

SPECIFICATIONS

  • Power source: Provided by NHX-50M
  • Capacity: 30 stations
  • Control Circuitry: NHR-30K, installed in NHX-80X
  • Wiring: Multi-pin connector plugs into NHX-50M
  • Material: High impact ABS fire-retardant plastic
  • Color: White
  • Dimensions
    • NHX-30G (H x W x D): 2-5/16” x 3-9/16” x 8-1/4”
    • NHX-50M + NHX-30G: 3-1/4” x 14-9/16” x 8-1/4”
  • Certification: UL 1069 Listed
  • C-UL Canadian Standard C22.2

Manufacturer Resources

NIM Nurse Call system Brochure

Product Specs

Product Type:
Add-On Selector
Series:
NHX Series
Subcategory:
Accessories
Commercial/Residential:
Commercial
Product Group:
Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Aiphone NHX-30G – Frequently Asked Questions

1) What does the Aiphone NHX-30G add-on selector actually do in a CommuniCare nurse call system?
The NHX-30G is a 30-station add-on selector that extends the Aiphone CommuniCare system to its full 80-station capacity. It hangs off the NHX-50M master station, so the master itself stays the same compact footprint while you gain 30 more call positions. Calls annunciate on the selector by LED and tone, with routine calls flashing slow and bathroom calls flashing fast, and the system auto-connects to the next call in priority order so staff do not have to pick a station manually.
2) Can I use the NHX-30G on its own, or do I need other Aiphone parts to make it work?
It will not work standalone. The NHX-30G has no power supply of its own, it draws power from the NHX-50M master station and plugs into it with a multi-pin connector. You also need the NHR-30K expansion trunk card installed in the NHX-80X central control unit, which supplies the extra call signaling and control circuitry for the added 30 stations. Without both the master and that card, the selector does nothing.
3) I already have a 50-call CommuniCare master. How many more stations can I add and can I add more than one selector?
One NHX-30G adds 30 stations, taking an NHX-50M-based CommuniCare system to the 80-station maximum. Eighty is the ceiling for the system, so a single 30-call selector is what gets you there, and there is no further expansion above that. The extra capacity is enabled by the NHR-30K expansion card in the NHX-80X central control unit.
4) How much wall or desk space do I need for the NHX-50M master with the NHX-30G selector attached?
Budget for a combined footprint of 3-1/4 x 14-9/16 x 8-1/4 inches once the NHX-50M and NHX-30G are joined. The selector alone measures 2-5/16 x 3-9/16 x 8-1/4 inches. The depth stays at 8-1/4 inches either way, so the added width is what drives the layout at a nurses station counter.
5) How do staff tell a bathroom call from a regular patient call on the NHX-30G?
Two cues, both on the selector itself. A routine call flashes the LED slowly, a bathroom call flashes fast, and each is paired with a tone. The system then auto-connects to the next call in priority, so an attendant clearing calls does not need to select each station by hand, which is the point of running the selector alongside the NHX-50M rather than a separate annunciator.
6) Is the NHX-30G rated for commercial healthcare use, and what is the housing made of?
It is a commercial-grade component, not a residential one, and the enclosure is high impact ABS fire-retardant plastic in white. That material and color match the rest of the CommuniCare master station hardware, so an added selector does not look like an afterthought on the counter.
