AL MULTI BOTHSIDE CONN 6PORT 350-10
Manufacturer Resources
Product Specs
- Country Of Origin:
- United States (US)
- Product Group:
- Wire & Cable Management
- Product Type:
- Multi-Tap/Port Connector
- Selling Unit Of Measure:
- each
- Standards:
- UL E9809, CSA 6591
- Type2:
- Electrical taps
- Voltage Rating:
- 600 V
- Department:
- Electrical
- Product Subgroup:
- Connectors
- Product Color:
- Black
- Product Material:
- Aluminum
Blackburn AMTD350106 – Frequently Asked Questions
1) How many conductor ports does the Blackburn AMTD350106 multi-tap connector have, and are they on both sides?
Six ports, and they are arranged on both sides of the block, so you can run conductors in from either direction rather than looping them all to one face. That makes it a multi-port tap block for splitting a single feed into multiple branch runs inside a panel, gutter, or pull box.
2) What wire size range does the AMTD350106 tap block accept?
The ports are rated 350 through 10, meaning 350 kcmil down to 10 AWG. One block handles both the large feeder conductor and much smaller branch taps, so you don't need a separate connector for the small legs.
3) Is the AMTD350106 UL listed for inspection sign-off?
It is covered under UL file E9809 and CSA file 6591, so it carries both US and Canadian listings. That is what an inspector or a spec writer on an institutional job will want to see cited for a tap block.
4) Is this Blackburn tap connector rated for 600 volt service?
Yes. The AMTD350106 carries a 600 V rating, which covers standard commercial and industrial branch and feeder work up to 600 volts.
5) What is the body of this 6-port tap block made of?
Aluminum, finished in black. It is a mechanical set-screw style tap block rather than a compression connector, so it is installed with a torque wrench or hex driver instead of a crimp tool.
6) What is the exact part number to order for the Blackburn 6-port 350-10 both-side tap?
Order Blackburn AMTD350106. That is the manufacturer part number for the aluminum 6-port both-side multi-tap connector rated 350 kcmil to 10 AWG at 600 V.
7) Is the AMTD350106 sold individually or in a pack?
It sells as each, one connector per unit, so order the exact count of tap blocks the job needs rather than a carton.
8) Is this Blackburn connector made in the USA?
Country of origin is the United States, which matters on government, school, and other publicly funded work carrying domestic sourcing requirements.
