Alarm Lock 103 Series Electric...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$473.05
$247.49
Alarm Lock Alarm Lock 103 - Electric Deadbolt, 24VAC/DC, Fail Safe ALA-103

Alarm Lock 103 Series Electric Deadbolt 24VAC/DC Fail-Safe Commercial Access Control System

(No reviews yet) Write a Review

Model: AL103

In Stock (leaves warehouse same day if ordered before 3pm ET)

$473.05
$247.49
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Alarm Lock 103 Series Electric Deadbolt 24VAC/DC Fail-Safe Commercial Access Control System

Professional Fail-Safe Access Control for Commercial Applications

The Alarm Lock 103 Series Electric Deadbolt delivers reliable fail-safe operation for commercial door security applications. This compact electric lock features 24VAC/DC power compatibility with 400mA current requirement and projects a 5/8" diameter bolt only while power is on, automatically retracting when power is off for safe egress. Built with molded aluminum construction and powered by a continuous duty solenoid, this deadbolt provides dependable remote access control through switches, time programmers, or other electrical contacts.

Professional Features & Benefits

  • Fail-Safe Operation: Bolt retracts automatically when power is off, ensuring safe emergency egress and code compliance for commercial environments.
  • 24VAC/DC Power Compatibility: Flexible dual voltage operation accommodates various electrical systems with 400mA current requirement for reliable performance.
  • 5/8" Deadbolt Projection: Standard security projection with 5/8" diameter bolt delivers effective door securing and meets commercial security requirements.
  • Continuous Duty Solenoid: Professional-grade powered operation designed for frequent use and long-term reliability in demanding commercial applications.
  • Molded Aluminum Construction: Durable cover material provides exceptional longevity and corrosion resistance in high-traffic environments.
  • Remote Control Integration: Compatible with key switches, time programmers, and electrical contact devices for comprehensive access management.
  • Compact Installation Design: Simple mounting on all door types without extensive modifications, reducing installation time and costs.

Technical Specifications

  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Fail-Safe/Fail-Secure: Fail-Safe
  • Product Category: Electronic Access Controls
  • Product Group: Parts and Accessories
  • Product Model: 103 Series
  • Product Subgroup: Parts and Accessories
  • Product Type: Deadbolts
  • Subcategory: Electromagnetic Locks

Installation & Operation

  1. Verify electrical requirements match available power supply. Confirm voltage (24VAC/DC) and current capacity (400mA) before proceeding.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Mount the unit in the specified location ensuring adequate clearance for wiring access, ventilation, and future service requirements.
  4. Route and connect wiring according to manufacturer wiring diagrams. Use appropriate wire gauge and connectors for the application.
  5. Configure operational settings including fail-safe operation per application requirements.
  6. Restore power and test all functions including normal operation, fail-safe bolt retraction, and integration with connected control systems.
  7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Retail Establishments
  • Educational Facilities
  • Healthcare Facilities
  • Government Buildings
  • Multi-Tenant Properties
  • Industrial Access Control

Why Choose Alarm Lock Quality?

Alarm Lock electric deadbolts provide proven reliability in commercial access control applications with molded aluminum construction and continuous duty solenoid design for long-term performance. The fail-safe operation meets safety requirements for emergency egress while professional-grade components and straightforward installation make this an ideal choice for demanding commercial environments requiring dependable electronic access control.

Product Specs

Product Group:
Parts and Accessories
Product Type:
Deadbolts
Commercial/Residential:
Commercial
Product Subgroup:
Parts and Accessories
Subcategory:
Electromagnetic Locks
Fail-safe / Fail-secure:
Fail-Safe
Product Model:
103 Series
Product Category:
Electronic Access Controls
Department:
Door Hardware

Alarm Lock AL103 – Frequently Asked Questions

1) Will the Alarm Lock 103 electric deadbolt stay locked if the power goes out?
No. The 103 is a fail-safe device, so the bolt projects only while power is applied and retracts as soon as power drops. On a power failure or a fire alarm relay drop the opening is free to open. If you need the door to stay secure through a power loss, the 103 is the wrong device and you want a fail-secure electric bolt instead.
2) What power supply do I need for an Alarm Lock 103 electric deadbolt?
24V, either AC or DC, drawing 400mA. Size the supply for that draw per door and remember the solenoid is continuous duty, so the 400mA is a standing load the whole time the door is locked, not an inrush figure. Ten doors on one supply means 4A of continuous 24V capacity.
3) How far does the bolt on the Alarm Lock 103 throw, and will it work with my strike?
The 103 throws a 5/8 inch diameter bolt. It is a round bolt, not a rectangular deadbolt face, so the strike hole in the frame or the mating plate has to accept a 5/8 inch round projection with enough depth behind it. A standard deadbolt strike cut for a rectangular latch face is not a drop-in for it.
4) Can I release an Alarm Lock 103 deadbolt from a front desk or on a schedule?
Yes. The 103 has no keypad, credential reader or cylinder of its own. It is switched by whatever you wire to it, a key switch, a push button at a desk, a time programmer, or any dry contact from an access control panel. Cut the 24V and the bolt retracts. That means the release device is a separate order line from the deadbolt itself.
5) Does the Alarm Lock 103 have to be mortised into the door?
No mortise cut is required. The 103 mounts on the surface, in a molded aluminum housing, and the manufacturer states it goes onto all door types without extensive modification. That makes it a practical retrofit on existing openings, including doors you do not want to machine, though you still need to get 24V wiring to the head or jamb where the unit sits.
6) Is the Alarm Lock 103 an electric strike or a maglock?
Neither. It is an electric deadbolt, a solenoid-driven bolt that throws into the frame or the floor rather than releasing a latch. An electric strike still needs a mechanical lockset with a latch in the door and only controls the keeper. A magnetic lock holds the door with a magnetic plate and no bolt at all. The 103 provides the locking itself, so no lockset is needed on the opening for security, and unlike a maglock it gives you a physical bolt in the frame.
7) What model do I order for the Alarm Lock 103 electric deadbolt?
One part number covers it: AL103, the 24VAC/DC fail-safe electric deadbolt. There is no handing to specify, no finish option and no voltage choice, since the unit takes 24V AC or DC on the same terminals. What you do have to add to the order is the release device (key switch, timer or contact) and the 24V supply.
8) Can I use an Alarm Lock 103 on a required exit door?
Its fail-safe action is what makes it usable on egress paths: drop the 24V and the bolt pulls back on its own, so tying it to the fire alarm or a power supply relay frees the door. But the 103 is switched electrically only, it has no mechanical release built into it, so whatever your local authority requires for manual egress at that opening, a request-to-exit device, a push bar, or a break-glass, is a separate item you wire into the power run.
9) Is the Alarm Lock 103 rated for commercial traffic, or is it a residential lock?
Commercial. Alarm Lock lists the 103 as a commercial electronic access control device, and the continuous duty solenoid is what makes it suitable for a door that cycles all day rather than a few times. Typical use is office buildings, retail, schools, healthcare, government and multi-tenant properties.
