AMT 2 PORT 350-6 DOUBLE SIDED CONN.
Manufacturer Resources
Product Specs
- Country Of Origin:
- United States (US)
- Product Group:
- Wire & Cable Management
- Product Type:
- Multi-Tap/Port Connector
- Selling Unit Of Measure:
- each
- Standards:
- UL E9809
- Type2:
- Electrical taps
- Voltage Rating:
- 600 V
- Department:
- Electrical
- Product Subgroup:
- Connectors
- Product Color:
- Black
- Product Material:
- Aluminum
Blackburn AMTD35062 – Frequently Asked Questions
1) What conductor range does the Blackburn AMTD35062 multi-tap connector accept?
The AMTD35062 is a 350-6 range connector, so each port takes conductors from 350 kcmil down to 6 AWG. It is a 2 port, double sided design, meaning the two ports open on opposite sides of the body rather than side by side, which is what you want when the run conductor comes in one way and the taps leave the other.
2) Is the Blackburn AMTD35062 rated for 600 volt service?
Yes, it carries a 600 V rating and is UL listed under file E9809, so it is suitable for 600 volt and below power distribution, panel, and service applications.
3) Can I use this Blackburn tap connector on both copper and aluminum conductors?
The connector body is aluminum, which is the standard AL9CU-style construction for dual-rated service on either copper or aluminum conductors. Follow the marking on the body for the rating that applies to your conductor, and use the correct joint compound on aluminum terminations.
4) Do I need insulating cover or tape over the AMTD35062, or is it already insulated?
This is a bare mechanical tap connector, not a pre-insulated one. The aluminum body is exposed once installed, so in an enclosure or splice you need to insulate it yourself with a snap-on cover, tape, or heat shrink to keep the 600 V rating intact in the finished joint.
5) Is the double sided version different from a standard 2 port tap where both ports are on the same face?
Yes. On the double sided AMTD35062 the two ports face opposite directions, so conductors enter from either end of the body. A same-side 2 port tap brings both conductors in on one face, which suits a tap off a run where both wires come from the same direction. Pick the double sided one when the conductors approach from opposite sides and you do not want to loop a cable back on itself in a tight gutter.
6) How many of these connectors come in a pack?
The AMTD35062 is sold each, one connector per unit. For a three phase plus neutral tap you would order four, one per conductor.
7) Where is the Blackburn AMTD35062 made, and is it acceptable for domestic-preference projects?
It is manufactured in the United States, which matters on federal, municipal, and institutional work carrying domestic sourcing requirements.
8) What part number do I quote to order this Blackburn 350-6 two port tap?
Order Blackburn AMTD35062. That is the manufacturer part number for the AMT series 2 port, double sided, 350 kcmil to 6 AWG connector.
