AMT 8 PORT 250-6 DOUBLE SIDED CONN.
Manufacturer Resources
Product Specs
- Country Of Origin:
- United States (US)
- Product Group:
- Wire & Cable Management
- Product Type:
- AMT Connector
- Selling Unit Of Measure:
- each
- Standards:
- UL E9809
- Type2:
- Electrical taps
- Voltage Rating:
- 600 V
- Department:
- Electrical
- Product Subgroup:
- Connectors
- Product Color:
- Black
- Product Material:
- Aluminum
Blackburn AMTD25068 – Frequently Asked Questions
1) What is the Blackburn AMTD25068 AMT connector used for?
It's a multi-tap (AMT) aluminum connector block used to tap or splice conductors in a panel, gutter, or enclosure. The AMTD25068 is an 8 port, double sided block, so ports are arranged on both sides of the body, letting you land the run on one side and the taps on the other instead of crowding everything into one face. Blackburn rates it for 600 V, and it's sold individually.
2) Is the Blackburn AMTD25068 UL listed for a 600 volt panel?
Yes. The AMTD25068 carries UL file E9809 and is rated 600 V, so it suits standard 600 V class distribution work, panelboards, gutters, and service equipment taps.
3) How many conductors can I land in the AMTD25068?
Eight ports total, split across two sides of the block. That gives you up to eight terminations in one connector, which is why electricians reach for it instead of stacking several single-tap lugs when feeding multiple branch conductors off one run.
4) What does the 250-6 in the AMTD25068 part number mean?
It's the conductor range the ports accept, 250 kcmil down to 6 AWG. If your feeder is larger than 250 kcmil or your taps are smaller than 6 AWG, this block is the wrong size and you'll need a different AMT range.
5) Can I use the AMTD25068 tap block on both copper and aluminum conductors?
The body is aluminum, which on Blackburn's AMT line is the dual-rated material used for both copper and aluminum conductors. Verify the CU/AL marking stamped on the block itself against your conductor before you terminate, since that marking is the governing rating for the installation.
6) Does the AMTD25068 come with an insulating cover?
The AMTD25068 is supplied as the bare connector block, one each. Insulating covers and boots for AMT blocks are separate items, so if the installation needs the tap insulated rather than relying on enclosure clearances, order the cover to match the block.
7) Should I use a double sided AMT block or a single sided one?
Pick double sided, like the AMTD25068, when the feeder comes in from one direction and the taps leave in the other. Conductors stay separated and bending room is easier to hold in a tight gutter. A single sided block puts every port on one face, which is simpler when all conductors enter from the same side, but it bunches the wire. Either way, the conductor range and voltage class have to match the job.
8) Is the Blackburn AMTD25068 made in the USA?
Yes, country of origin is the United States. That matters for Buy American and domestic-preference procurement on federal, municipal, and institutional jobs where the submittal has to show origin.
