Metallics TS4070SS Anchors 1/2 x 7 Wdg SS (Box 25)

A 1/2 inch wedge anchor like the TS4070SS goes into a 1/2 inch hole, drilled with a carbide hammer bit. Wedge anchors are matched one to one with bit diameter, so the anchor body slips through the hole and the clip expands against the wall when you torque the nut. Drill deeper than the embedment you need so dust can settle below the anchor, and blow the hole clean before setting.

Wedge anchors, including the 1/2 x 7 TS4070SS, are for solid concrete. The expansion clip needs dense, uncracked base material to grip. In hollow block, brick, or mortar joints the clip can blow out the cell wall, so use a sleeve anchor or an adhesive anchor with a screen tube there instead.

Yes, where the anchor is exposed to weather, washdown, pool chemicals, or coastal air. The TS4070SS is stainless, so it resists the rust that lifts and stains zinc plated carbon steel anchors at the concrete surface. For dry interior slabs and non-corrosive conditions, a zinc plated wedge anchor of the same 1/2 x 7 size does the same mechanical job.

Twenty five anchors per box, packed as a box quantity. Each one is a complete assembly with the nut and washer on the stud, so you are not buying hardware separately. For a repeat spec job, order by the box count rather than the piece and keep a few spares, since a wedge anchor that spins in an oversized or dirty hole has to be abandoned and re-drilled nearby.
