Anchors 3/4 x 4-3/4 Wdg SS (Jar 20)
Manufacturer Resources
Product Specs
- Division:
- Electrical H1
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
- Product Subgroup:
- Anchors
Metallics JTS6434SS – Frequently Asked Questions
1) Are these Metallics wedge anchors stainless steel or plated?
Stainless steel, which is why they get specified for exterior slabs, wet areas, pool decks, and coastal work where a zinc plated anchor would bleed rust. The JTS6434SS is a 3/4 x 4-3/4 stainless wedge anchor.
2) Can I use a 3/4 inch wedge anchor in block or brick instead of concrete?
No. Wedge anchors like the JTS6434SS are for solid, poured concrete only. The expansion clip needs solid aggregate to bite into, and in hollow block or brick it either spins in the void or cracks the face shell. Use a sleeve anchor or a screen tube with adhesive in masonry.
3) How much of the 4-3/4 inch length is usable for the fixture I am bolting down?
Total length is 4-3/4 inches, and that is split between embedment in the concrete and the stickout that carries your fixture, washer and nut. On a wedge anchor you set embedment by how deep you drive it, so thick base plates or a shim stack eat into holding depth. Measure your fixture thickness plus nut and washer, subtract from 4-3/4 inches, and confirm what is left meets the embedment your engineer or the fixture spec calls for.
4) How many anchors come in a jar of Metallics JTS6434SS?
20 anchors per jar. That is the stock pack, so a single order unit covers a 20 hole layout of 3/4 inch stainless wedge anchors without breaking into a second container.
5) Do I need anything else to install these 3/4 inch wedge anchors?
The nut and washer come assembled on a wedge anchor, so no separate hardware is needed to make the connection. On site you will want a rotary hammer with a 3/4 inch carbide bit, a blow out bulb or vacuum to clear the hole, and a socket to torque the nut.
6) Can a wedge anchor be removed or reused once it is set?
No. Once the JTS6434SS is driven and torqued, the expansion clip is locked into the concrete. The nut comes off and the stud can be cut flush or driven below the surface, but the anchor itself does not come back out and cannot be reused. If you need a removable fastener in concrete, use a threaded insert or a drop-in anchor instead.
7) Will stainless wedge anchors work for galvanized or stainless strut and equipment rails?
Yes, and that is the usual reason to pay for them. Pairing a stainless 3/4 x 4-3/4 anchor with stainless or galvanized strut, pipe supports, or outdoor equipment bases avoids dissimilar metal corrosion at the bolt, which is the first thing to fail on exterior electrical and mechanical supports.
