Arrow 16SAT-88A AM/BM Series G Escutcheon Less Bushing, Inside Functions 02/11/13/15/16/19/21, Bright Brass

Arrow 16SAT-88A AM/BM Series G Escutcheon Less Bushing, Inside Functions 02/11/13/15/16/19/21, Bright Brass

(No reviews yet) Write a Review

Model: 16SAT-88A 26D

In Stock (leaves warehouse same day if ordered before 3pm ET)

$134.84
$132.24
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Arrow 16SAT-88A AM/BM Series G Escutcheon Less Bushing, Bright Brass Replacement Part

The Arrow 16SAT-88A is a genuine AM/BM Series G Escutcheon Less Bushing, engineered as a precision replacement part for Arrow AM/BM Series commercial lock cases. Finished in Bright Brass, this inside escutcheon is compatible with inside functions 02, 11, 13, 15, 16, 19, and 21, making it a versatile component for restoring or completing Arrow AM/BM Series locksets in commercial environments. As a manufacturer-sourced Arrow part, it ensures proper fit and finish integrity for professional service and maintenance applications.

Key Features

  • Genuine Arrow Replacement Part: Manufactured to exact Arrow AM/BM Series specifications, ensuring proper fit, function, and finish match for professional locksmith and maintenance applications.
  • AM/BM Series G Compatibility: Specifically designed for Arrow AM/BM Series G lock cases, maintaining the mechanical integrity of the original installation.
  • Wide Inside Function Coverage: Compatible with inside functions 02, 11, 13, 15, 16, 19, and 21, providing broad versatility across multiple AM/BM Series configurations.
  • Less Bushing Design: Supplied without bushing, allowing integration with existing bushing hardware or enabling selection of the appropriate bushing for the specific application.
  • Bright Brass Finish: Features a Bright Brass finish to match existing Arrow AM/BM Series hardware, preserving a consistent aesthetic appearance on door hardware assemblies.
  • Commercial-Grade Construction: Designed for commercial applications where dependable component performance and long-term serviceability are required.

Technical Specifications

  • Department: Door Hardware
  • Product Category: Mechanical Locks
  • Product Group: Parts and Accessories
  • Subcategory: Parts and Accessories
  • Product Subgroup: Parts and Accessories
  • Product Type: Lock Cases
  • Parts and Accessories Type: Replacement Parts
  • Commercial/Residential: Commercial
  • Product Model: 16SAT-88A
  • Features: Arrow Parts

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Government and Municipal Buildings
  • Multi-Tenant Residential Properties
  • Industrial and Warehouse Facilities

Why Arrow 16SAT-88A?

Arrow lock components are manufactured to precise tolerances, ensuring seamless compatibility with original Arrow AM/BM Series hardware for reliable restoration and maintenance. The 16SAT-88A escutcheon delivers a factory-matched fit and Bright Brass finish, making it the professional-grade choice for locksmiths and facility maintenance teams servicing Arrow commercial locksets.
