Arrow R23 Springlatch Replacement Part for MLX and RLX Series with 2-3/4" Backset and 2-1/4" x 1-1/8" Face

(No reviews yet) Write a Review

Model: R23 613E

In Stock (leaves warehouse same day if ordered before 3pm ET)

$32.37
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Arrow R23 Springlatch Replacement Part for MLX and RLX Series, 2-3/4" Backset, Oil Rubbed Bronze

The Arrow R23 Springlatch is a commercial-grade replacement part engineered for compatibility with Arrow's MLX and RLX Series locksets. Featuring a 2-3/4" backset and a 2-1/4" x 1-1/8" face plate, this springlatch delivers a precise, drop-in fit for maintaining smooth latch operation in demanding commercial door hardware applications. Finished in Oil Rubbed Bronze (613E), it provides both functional reliability and a consistent aesthetic match for compatible series hardware.

Key Features

  • Precise Backset Dimension: 2-3/4" backset ensures accurate alignment and compatibility with standard commercial door preparations for MLX and RLX Series locksets.
  • Exact Face Plate Dimensions: 2-1/4" x 1-1/8" face plate provides a flush, professional fit within the door edge mortise cutout.
  • MLX and RLX Series Compatibility: Designed specifically as a replacement latch for Arrow MLX and RLX Series locksets, streamlining service and maintenance on existing hardware.
  • Oil Rubbed Bronze Finish (613E): Matches existing Arrow MLX and RLX Series hardware finishes for a cohesive appearance on door assemblies.
  • Commercial-Grade Construction: Built to Arrow's commercial parts standards for lasting performance in high-use door applications.
  • Springlatch Mechanism: Spring-loaded latch design allows for smooth, self-latching door operation without requiring a key or thumbturn for latch engagement.
  • Genuine Arrow Replacement Part: Sourced as an authentic Arrow component, ensuring proper fit and performance within supported series locksets.

Technical Specifications

  • Department: Door Hardware
  • Product Category: Mechanical Locks
  • Product Group: Parts and Accessories
  • Subcategory: Parts and Accessories
  • Product Subgroup: Parts and Accessories
  • Product Type: Latches
  • Parts and Accessories Type: Replacement Parts
  • Commercial/Residential: Commercial
  • Product Model: R23 613E
  • Features: Arrow Parts

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Multi-Tenant Residential Properties
  • Industrial and Warehouse Facilities
  • Government and Municipal Buildings

Why Arrow R23?

Arrow's R23 Springlatch reflects the brand's commitment to commercial-grade door hardware reliability. As a genuine Arrow replacement part, the R23 is engineered to restore precise latch function to MLX and RLX Series locksets, maintaining the performance integrity of the original installation. For facilities managers and hardware professionals seeking dependable, specification-matched components, Arrow parts deliver the quality and fit accuracy that commercial applications demand.
