Spec Sheet
Product Specs
- Display:
- Meter Faceplate
- Meter Type:
- IQ 100/200 Series
- Nema Rating:
- NEMA 3R
- Number Of Meters:
- 1
- Power Supply:
- 480 Vac w/ CPT
- Department:
- Electrical
- Product Length:
- 13 IN
- Product Height:
- 21 IN
- Product Weight:
- 25 LB
- Product Width:
- 11 IN
B-LINE IQ260MA65110-3B – Frequently Asked Questions
1) Can the B-Line IQ260MA65110-3B enclosed meter be mounted outdoors?
Yes. The enclosure on the IQ260MA65110-3B carries a NEMA 3R rating, so it is built for outdoor wall mounting where it will see rain and sleet. NEMA 3R is rain-tight, not wash-down or dust-tight, so keep it off surfaces that get hosed down or see heavy airborne dust.
2) Does this B-Line enclosed meter come with Modbus or Ethernet communications?
No. The IQ260MA65110-3B is built with no communication option, so there is no Modbus, Ethernet or other network card in it. Readings are taken locally off the meter faceplate. If you need data pushed back to a BMS or energy dashboard, you need a version ordered with a communications option.
3) How many meters are in the B-Line IQ260MA65110-3B enclosure, and can I add a second one later?
It is a single-meter assembly: one IQ 100/200 Series meter behind a faceplate in the enclosure. It is not a multi-meter panel, so for tenant sub-metering across several loads you would order separate enclosed units or a multi-meter enclosure rather than trying to stuff a second meter into this one.
4) What wall space do I need to mount the B-Line Eaton enclosed meter, and how heavy is it?
Plan for an enclosure measuring 21 in height, 13 in length and 11 in width, weighing 25 lb. At that weight it is a one-person hang, but put it into studs, blocking or Unistrut rather than drywall anchors, and leave yourself clearance below for conduit entry and CT leads.
5) Why buy an enclosed meter instead of mounting an IQ meter in a panel door?
An enclosed unit like this one arrives as a finished assembly: the IQ 100/200 Series meter, the faceplate and the 480 Vac control power transformer already in a NEMA 3R box. You mount it, land power and CTs, and you are done. Flush-mounting a bare meter in switchgear or a panel door means cutting the door, providing your own control power and giving up the outdoor rating. Pick the enclosed version for retrofits, outdoor service entrances, and anywhere you do not want to cut into existing gear.
6) Where can I get the full electrical specifications for B-Line IQ260MA65110-3B?
The Eaton spec sheet for model IQ260MA65110-3B is linked directly from the product description, and that is the document to hand your engineer for wiring detail and CT input data. The part number to quote is IQ260MA65110-3B.
