B-Line Eaton Quicklag Type QCH...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$400.00
B-Line Eaton Quicklag Type QCHW Industrial Thermal-Magnetic Circuit Breaker,Industrial miniature ,45 A,22 kAIC,Two-pole,120/240 V,Thermal-magnetic,Cab

B-Line Eaton Quicklag Type QCHW Industrial Thermal-Magnetic Circuit Breaker,Industrial miniature ,45 A,22 kAIC,Two-pole,120/240 V,Thermal-magnetic,Cab

(No reviews yet) Write a Review

Model: QCHW2045
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$400.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton Quicklag Type QCHW Industrial Thermal-Magnetic Circuit Breaker,Industrial miniature circuit breaker,45 A,22 kAIC,Two-pole,120/240 V,Thermal-magnetic,Cable-in,QCHW

Manufacturer Resources

Product Specs

Amperage Rating:
45 A
Certifications:
UL Listed
Circuit Breaker Type:
QCHW
Connection:
Cable-in/cable-out
Interrupt Rating:
22 kAIC
Number Of Poles:
Two-pole
Product Height:
5 in
Product Length Depth:
3 in
Product Weight:
3 lb
Product Width:
.6 in
Trip Type:
Thermal-magnetic
Voltage Rating:
120/240 V
Department:
Electrical
Product Group:
Electrical Components
Product Subgroup:
Circuit Breakers
Product Type:
Industrial miniature circuit breaker
Product Details:
Industrial miniature circuit breaker

B-LINE QCHW2045 – Frequently Asked Questions

1) Does the QCHW2045 circuit breaker land wire directly, or does it plug onto a panel bus?
It is a cable-in/cable-out device, so conductors terminate on both the line and load sides of the breaker itself. That makes it suited to enclosed or standalone industrial applications rather than dropping onto a loadcenter bus stab. Plan your raceway and conductor entry accordingly, because there is no bus connection to rely on.
2) What size load will a 45 amp two-pole Quicklag QCHW breaker protect?
The QCHW2045 is a two-pole, 45 amp device rated 120/240 V, so it protects a 240 V line-to-line load such as a compressor, heater, or feeder to a small subpanel. Both poles trip together on a fault on either leg. For a 120 V single-phase branch circuit you would want a single-pole device instead.
3) Is the QCHW2045 thermal-magnetic or electronic trip?
Thermal-magnetic. The bimetal element handles sustained overloads with an inverse time delay, and the magnetic element clears short circuits instantaneously. That combination tolerates normal motor inrush without nuisance tripping, which is why it is specified on industrial branch circuits.
4) What are the dimensions of the QCHW2045 breaker for enclosure layout?
The published dimensions are 5 in, 3 in, and .6 in, with a product weight of 3 lb. Use the .6 in figure when you are counting pole spacing in an enclosure, since the two-pole device occupies its poles side by side.
