Eaton Quicklag Type QCR Industrial Miniature Thermal-Magnetic Circuit Breaker,Industrial miniature circuit breaker,25 A,10 kAIC,Two-pole,120/240 V,Thermal-magnetic,Cable-in, Ring lug,QCR
Manufacturer Resources
Spec Sheet
Product Specs
- Amperage Rating:
- 25A
- Catalog Notes:
- Standard breaker terminals are box type lugs. Suitable for line and load side ring terminal connection (#10-32 plus/minus terminal screw provided). HACR rated.
- Certifications:
- UL Listed
- Circuit Breaker Type:
- QCR
- Connection:
- Cable-in/cable-out
- Interrupt Rating:
- 10 kAIC
- Number Of Poles:
- Two-pole
- Product Height:
- 5 in
- Product Length Depth:
- 5 in
- Product Weight:
- 3.2 lb
- Product Width:
- .45 in
- Trip Type:
- Thermal-magnetic
- Voltage Rating:
- 120/240V
- Department:
- Electrical
- Product Group:
- Electrical Components
- Product Subgroup:
- Circuit Breakers
- Product Type:
- Industrial miniature circuit breaker
- Product Details:
- Industrial miniature circuit breaker
B-LINE QCR2025T – Frequently Asked Questions
1) Will the Eaton Quicklag QCR2025T work on a 240V single-phase circuit?
Yes. The QCR2025T is a two-pole breaker rated 120/240 V, so it covers a 240 V single-phase two-wire circuit or a 120/240 V multiwire branch circuit. At 25 A it is the size typically used for smaller two-pole loads like a compressor or a small heater circuit.
2) Can I use this QCR breaker on an air conditioning or heat pump circuit?
It is HACR rated, so it can be used as the branch circuit protective device on heating, air conditioning and refrigeration equipment where the nameplate calls for an HACR type breaker. Confirm the equipment nameplate maximum overcurrent device is 25 A or higher before installing.
3) What terminals does the Quicklag QCR2025T come with, and will it take a ring lug?
It ships with box type lugs as standard and is cable-in/cable-out. It is also suitable for ring terminal connection on both line and load side, and a #10-32 terminal screw is provided for that. So you can land stranded conductors directly or crimp ring terminals, no separate kit needed.
4) What does thermal-magnetic trip mean on this breaker versus an electronic trip unit?
Thermal-magnetic means two trip elements in one breaker: a bimetal that responds to sustained overload with a time delay, and a magnetic element that trips instantly on a short circuit. The curve is fixed, nothing to adjust or program. That is what you want for ordinary branch circuits and motor loads; electronic trip units are for large frame breakers where you need adjustable pickup and delay for selective coordination.
5) Is the Quicklag QCR2025T UL Listed for use in commercial and institutional buildings?
Yes, it carries a UL Listing, which is what an inspector and most institutional specs require for a branch circuit breaker. It is an industrial miniature circuit breaker of the QCR type.
6) What is the exact part number to order for a 25 amp two-pole Quicklag QCR?
Order QCR2025T. That is the Eaton Quicklag Type QCR industrial miniature breaker, two-pole, 25 A, 120/240 V, 10 kAIC, thermal-magnetic. Anyone standardizing a facility on QCR breakers can quote that number directly.
7) How wide is the QCR2025T and how much room does it need?
Published dimensions are 5 in height, 5 in length/depth and .45 in width, and it weighs 3.2 lb. Use the .45 in figure when you are counting available spaces in a tight enclosure or gutter.
