Eaton B-Line series beam clamps, Vertical adjustment provided in the clamp, Steel beam clamp, 1"-8 thread/rod size, Plain
Manufacturer Resources
Product Specs
- Application:
- Vertical adjustment provided in clamp
- Certifications:
- cULus Listed
- Load Capacity:
- 4300 lb
- Product Height:
- 5.5 in
- Product Length Depth:
- 5.5 in
- Product Weight:
- 8.7 lb
- Product Width:
- 6 in
- Thread Rod Size:
- 1"-8
- Department:
- Electrical
- Product Group:
- Conduit & Fittings
- Product Subgroup:
- Tees / Crosses
- Product Type:
- Steel beam clamp
- Product Details:
- Steel beam clamp
- Product Material:
- Steel
B-LINE B3055-1X6PLN – Frequently Asked Questions
1) Do I need a separate rod coupling or nut to set the drop height with this clamp?
No, vertical adjustment is built into the clamp, so you set the drop at the clamp rather than adding a coupling or cutting rod to length. That is the main reason to pick the B3055-1X6PLN over a fixed-tap beam clamp on a job where the steel is not all at one elevation.
2) What finish is the B3055-1X6PLN, and can I hang it outdoors?
It is plain steel, meaning uncoated, so it is intended for dry interior locations. For exterior, damp or corrosive areas specify a galvanized or plated version of the beam clamp instead of the plain finish.
3) How much room does this beam clamp need around the beam flange?
Overall it measures 5.5 in high, 5.5 in deep and 6 in wide, so allow roughly a 6 inch envelope around the flange. Worth checking where beams sit tight to deck or where another trade's duct or tray runs close to the steel.
4) What exact part number do I order for the 1 inch plain beam clamp with built-in vertical adjustment?
Order Eaton B-Line B3055-1X6PLN. The 1X6 is the 1"-8 thread size and PLN is the plain (uncoated) finish.
