B-Line Eaton Series C complete...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$4,490.00
B-Line Eaton Series C complete , F-, FDC, Complete , Fixed thermal, fixed magnetic trip type, Two-pole, 70A, 600 Vac, 250 Vdc, 200 kAIC at 240 Vac, 1

B-Line Eaton Series C complete , F-, FDC, Complete , Fixed thermal, fixed magnetic trip type, Two-pole, 70A, 600 Vac, 250 Vdc, 200 kAIC at 240 Vac, 1

(No reviews yet) Write a Review

Model: FDC2070L
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$4,490.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton Series C complete molded case circuit breaker, F-frame, FDC, Complete breaker, Fixed thermal, fixed magnetic trip type, Two-pole, 70A, 600 Vac, 250 Vdc, 200 kAIC at 240 Vac, 100 kAIC at 480 Vac, Line and load, 50/60 Hz

FDC2070L - spec sheet

Manufacturer Resources

Spec Sheet

Product Specs

Amperage Rating:
70A
Certifications:
UL Listed
Circuit Breaker Frame Type:
Complete breaker
Circuit Breaker Type:
FDC
Frame:
F-frame
Frequency Rating:
50/60 Hz
Interrupt Rating:
200 kAIC at 240 Vac, 100 kAIC at 480 Vac
Number Of Poles:
Two-pole
Product Height:
6 IN
Product Length Depth:
3.38 IN
Product Weight:
2 LB
Product Width:
2.75 IN
Series:
Series C
Terminals:
Line and load
Trip Type:
Fixed thermal, fixed magnetic
Voltage Rating:
600 Vac, 250 Vdc
Department:
Electrical

B-LINE FDC2070L – Frequently Asked Questions

1) Will the Eaton FDC2070L handle a 65 kAIC available fault current at 480V?
Yes. The FDC2070L is rated 200 kAIC at 240 Vac and 100 kAIC at 480 Vac, so a 65 kAIC available fault at 480 volts is well inside its interrupting capacity. That high-interrupting rating is what the C suffix in the FDC catalog number signifies compared with a standard F-frame FD.
2) Can the FDC2070L be used on a 600V three-phase system or on DC?
The FDC2070L is rated 600 Vac and 250 Vdc, so it can be applied up to 600 volts AC and on DC systems to 250 volts. It is a two-pole breaker, so on a three-phase system it covers two phases only; a three-phase feeder needs the three-pole version of the F-frame. Frequency rating is 50/60 Hz.
3) Is the trip setting on the Eaton FDC2070L adjustable?
No. This 70A F-frame breaker uses a fixed thermal, fixed magnetic trip unit, so neither the overload nor the instantaneous pickup can be dialed in. If your coordination study calls for an adjustable instantaneous setting, you need an adjustable-trip F-frame instead of this one.
4) Does the FDC2070L come with lugs, or do I have to order terminals separately?
Line and load terminals are included with the FDC2070L, so the breaker arrives ready to land conductors on both ends. It is also supplied as a complete breaker, meaning the frame and trip unit ship as one assembled unit rather than as a separate frame and rating plug.
5) What size enclosure or panel space does an Eaton F-frame FDC2070L need?
The two-pole FDC2070L measures 6 in height, 2.75 in width and 3.38 in length/depth, and weighs 2 lb. Use the 3.38 in depth figure when checking gutter space behind the deadfront in a small enclosure or a tight control panel.
6) What is the difference between an Eaton FD and an FDC breaker in the Series C line?
Both are F-frame molded case breakers in Eaton's Series C family and share the same frame footprint. The difference is interrupting capacity: the FDC is the high-interrupting version, rated 200 kAIC at 240 Vac and 100 kAIC at 480 Vac. Pick the FDC when the available fault current at the equipment exceeds what a standard FD is rated for.
7) What exact part number should I order for a 70A two-pole Eaton F-frame high-interrupting breaker?
Order Eaton catalog number FDC2070L. It is the two-pole, 70 amp complete F-frame breaker in the Series C line, fixed thermal and fixed magnetic trip, with line and load terminals.
