B-Line PWK53SS Eaton series window and door kit, ANSI 61 gray polyester powder coated, Stainless steel, Fixed window, Plexiglas window kit, Enclosure cut-out 6.62" X 4.62"
Model: BLN-PWK53SS
Eaton B-Line series window and door kit, ANSI 61 gray polyester powder coated, Stainless steel, Fixed window, Plexiglas window kit, Enclosure cut-out 6.62" X 4.62"
B-LINE
$1,201.68
B-Line Eaton series window and door kit, ANSI 61 gray polyester powder coated, Stainless steel, Fixed window, Plexiglas window kit, Enclosure cut-out
Model: BLN-PWK133SS
Eaton B-Line series window and door kit, ANSI 61 gray polyester powder coated, Stainless steel, Fixed window, Plexiglas window kit, Enclosure cut-out 14.62" X 4.62"
B-LINE
$1,311.39
B-Line Eaton series window and door kit, ANSI 61 gray polyester powder coated, Steel, Fixed window, Plexiglas window kit, Enclosure cut-out 14.62" X 4
Model: BLN-PWK133
Eaton B-Line series window and door kit, ANSI 61 gray polyester powder coated, Steel, Fixed window, Plexiglas window kit, Enclosure cut-out 14.62" X 4.62"
B-LINE
$827.00
B-Line Eaton series window and door kit, ANSI 61 gray polyester powder coated, Steel, Fixed window, Plexiglas window kit, Enclosure cut-out 18.62" X 1
Model: BLN-PWK1711
Eaton B-Line series window and door kit, ANSI 61 gray polyester powder coated, Steel, Fixed window, Plexiglas window kit, Enclosure cut-out 18.62" X 12.62"
B-LINE
$1,588.18
B-Line Eaton series window and door kit, ANSI 61 gray polyester powder coated, Steel, Fixed window, Plexiglas window kit, Enclosure cut-out 10.62" X 7
Model: BLN-PWK95
Eaton B-Line series window and door kit, ANSI 61 gray polyester powder coated, Steel, Fixed window, Plexiglas window kit, Enclosure cut-out 10.62" X 7.12"
B-LINE
$913.08
Eaton B-Line series window and door kit, ANSI 61 gray polyester powder coated, Steel, Fixed window, Plexiglas window kit, Enclosure cut-out 6.62" X 4.62"
Manufacturer Resources
Product Specs
- Certifications:
- UL Listed
- Finish Color:
- ANSI 61 gray painted
- Product Category:
- Plexiglas window kit
- Product Height:
- 6.62 in
- Product Length Depth:
- 5.53 in
- Product Weight:
- 2.114 lb
- Product Width:
- 4.62 in
- Department:
- Electrical
- Product Type:
- Type 12/13 Fixed window
- Product Details:
- Type 12/13 Fixed window
- Product Material:
- Steel
B-LINE PWK53 – Frequently Asked Questions
1) What size cutout do I need in my enclosure door for the B-Line PWK53 window kit?
The PWK53 Plexiglas window kit drops into a rectangular enclosure cut-out of 6.62 inches by 4.62 inches. Lay that opening out on the door face before you cut, and leave enough flat, unobstructed surface around it for the frame to seat and gasket properly. If your existing opening is larger than 6.62 x 4.62, this kit will not cover it and you need a bigger window kit.
2) Will a window kit keep my Type 12 enclosure rated for oil and dust?
The PWK53 is built as a Type 12/13 fixed window, so it is intended for enclosures in those ratings, where dust, dripping liquids and coolant spray are the concern. It is a fixed window, not a hinged or opening one, so there is no moving seal to fail. It is UL Listed. It is not intended for outdoor or washdown Type 4/4X duty.
3) Is the B-Line PWK53 window frame steel or plastic?
The frame is steel, finished in ANSI 61 gray polyester powder coat. The viewing pane itself is Plexiglas. The gray paint is the same standard shade used on most industrial control enclosures, so the kit blends with a stock B-Line or comparable ANSI 61 cabinet rather than standing out.
4) How much room does the PWK53 window kit take up behind the enclosure door?
Overall the kit measures 6.62 inches high, 4.62 inches wide, and 5.53 inches in the length/depth dimension, at 2.114 lb. Check clearance against any DIN rail, wireway or device mounted directly behind the door face so the frame and hardware are not fouled when the door swings shut.
5) Can I open the PWK53 window to get at the meters inside?
No. The PWK53 is a fixed window, meant only for reading meters, indicator lights or breaker positions without opening the cabinet. If you need access through the opening itself, you want a hinged window and door kit instead, not this one.
6) What part number do I order for this B-Line gray Plexiglas window kit?
Order it as Eaton B-Line PWK53. That single model covers the ANSI 61 gray steel frame with the Plexiglas pane for a 6.62 by 4.62 inch cut-out; there are no finish or size options to specify with it.
