Eaton B-Line series window and door kit, ANSI 61 gray polyester powder coated, Stainless steel, Fixed window, Plexiglas window kit, Enclosure cut-out 6.62" X 4.62"
Manufacturer Resources
Product Specs
- Certifications:
- UL Listed
- Finish Color:
- ANSI 61 gray painted
- Product Category:
- Plexiglas window kit
- Product Height:
- 6.62 in
- Product Length Depth:
- 5.53 in
- Product Weight:
- 2.142 lb
- Product Width:
- 4.62 in
- Department:
- Electrical
- Product Type:
- Type 12/13 Fixed window
- Product Details:
- Type 12/13 Fixed window
- Product Material:
- Stainless steel
B-LINE PWK53SS – Frequently Asked Questions
1) What size cut-out do I need in my enclosure door for the B-Line PWK53SS window kit?
The PWK53SS Plexiglas window kit mounts into a rectangular cut-out of 6.62 x 4.62 inches. Lay that out on the enclosure door before you cut, since the frame is sized to cover that opening and nothing larger. The kit body itself measures 6.62 high, 4.62 wide, and 5.53 in depth per the published dimensions.
2) Will a window kit like this keep my Type 12 enclosure rated for oil and dust?
Yes. The PWK53SS is built as a Type 12/13 fixed window, so it is intended for dust-tight and oil-tight enclosures and it is UL Listed. Gasketing and even clamping pressure around the full perimeter of the cut-out are what preserve that rating in the field, so mount it flat and torque the frame down evenly.
3) Does the PWK53SS window open, or is it sealed shut?
It is a fixed window, not a hinged or latching one. You get a clear Plexiglas viewing pane for reading meters, indicator lights, or breaker positions without opening the enclosure. If you need to reach the equipment behind the glass, you still open the enclosure door.
4) Is the window kit frame stainless steel, and will it match my gray painted enclosure?
The frame is stainless steel finished in ANSI 61 gray polyester powder coat, which is the standard gray used on most industrial electrical enclosures, so it blends with a typical ANSI 61 cabinet rather than standing out. The stainless substrate is the reason it holds up in washdown and damp plant areas.
5) What is the Eaton part number for this Plexiglas window kit?
Order it as PWK53SS, an Eaton B-Line series window and door kit. That single part number covers the complete kit for a 6.62 x 4.62 inch enclosure cut-out.
6) Can one person hang this window kit on an enclosure door without help?
Yes, it is a one-hand part. The kit weighs 2.142 lb, so on a mounted enclosure door you can hold it in the cut-out and start the fasteners yourself. The cut itself is the labor, not the mounting.
