B40STD1090 1"x90D PVC STD ELBOW SPxBE SCH40 KRALOY
Certifications and Standards
- NAFTA
- UL 651
Features
- Feature a bell end for use with nonmetallic solvent weld fittings
- Approved for use in exposed, concrete encased and direct burial applications
- Made from impact resistant Schedule 40 rigid nonmetallic PVC
Applications
- Bridges & Tunnels
- Mines
- Airports
- Marinas
- Food Processing Plants
- Fish Plants
- Car Washes
- Subways
- Water/Sewage Treatment Plants
- Pulp & Paper Industries
- Parking Garages
- Communications
- Cable
- Steel Mills
- Street & Highway Lighting
- Utilities
- Agricultural
- Residential
Manufacturer Resources
Product Specs
- Product Type:
- PVC Elbow
- Department:
- Electrical
- Product Subgroup:
- PVC Conduit & Fittings
- Connection Type:
- Spxbe
- Product Material:
- PVC
- Product Diameter:
- 1 in
- Product Group:
- Conduit & Raceway
Kraloy 78590 – Frequently Asked Questions
1) Is the Kraloy 78590 elbow a 1 inch Schedule 40 PVC conduit fitting?
Yes. The Kraloy B40STD1090 (part 78590) is a 1 inch, 90 degree standard radius elbow made from impact resistant Schedule 40 rigid nonmetallic PVC conduit material.
2) What are the two ends on the Kraloy B40STD1090 elbow, and do I need a coupling?
It is SPxBE: one spigot end and one bell end. The bell end accepts a length of 1 inch Schedule 40 conduit solvent welded straight in, so no separate coupling is needed on that side. The spigot end glues into the bell of the next fitting or coupling.
3) Can this PVC elbow be direct buried or encased in concrete?
Yes. The Kraloy 1 inch 90 degree Schedule 40 elbow is approved for exposed, concrete encased and direct burial installations, which covers a slab turn-up out of a duct bank as well as an above-grade run on a wall.
4) Is the Kraloy 78590 PVC elbow UL listed?
It is built to UL 651, the standard for rigid nonmetallic PVC conduit and fittings, and is also noted as NAFTA compliant. UL 651 is the listing inspectors look for on PVC conduit elbows.
5) Will this elbow work in a car wash or wastewater plant where metal conduit corrodes?
That is one of its intended uses. PVC conduit elbows like this one are called out for water and sewage treatment plants, car washes, food processing and fish plants, marinas, mines, pulp and paper, and steel mills, all places where damp or chemical exposure eats at metal raceway.
6) Is this a standard radius or a long sweep 90 for a pull?
Standard radius. The B40STD1090 is the tighter STD bend, which is what you want for turning a wall or stubbing up at a box. For long cable pulls where sidewall pressure matters, use a long radius or special radius 1 inch 90 instead.
7) Do I need a different cement for a Schedule 40 electrical PVC elbow than for plumbing PVC?
Use PVC conduit solvent cement rated for electrical nonmetallic raceway. The bell end on this elbow is made for solvent weld fittings, so the joint is a cemented socket joint, not threaded and not a gasket.
8) Can I use this elbow for street lighting and utility runs, or is it residential only?
Both. The 1 inch Schedule 40 elbow is listed for street and highway lighting, utilities, communications and cable, parking garages, bridges and tunnels, airports, subways, agricultural and residential work.
