BALDWIN Estate 8300 Compression Cylinder Collar
KEY FEATURES
- Dimension 1-7/8" Diameter
- Series Estate
- Material Brass
- Limited Lifetime Mechanical Warranty and Limited Lifetime Finish Warranty
Manufacturer Resources
Product Specs
- Product Group:
- Door Trim and Accessories
- Product Type:
- Parts and Accessories
- Subcategory:
- Parts and Accessories
- Product Subgroup:
- Parts and Accessories
- Commercial/Residential:
- Residential
- Collection:
- Estate Series
- Product Model:
- 8300
- Product Dimension:
- 1-7/8" Diameter
- Product Substrate:
- Brass
- Product Category:
- Door Trim and Accessories
- Department:
- Door Hardware
Baldwin 8300031 – Frequently Asked Questions
1) What does a Baldwin 8300 compression cylinder collar actually do?
The 8300 is the trim ring that sits between the cylinder and the door face on Baldwin Estate Series hardware. It's the collar, not the cylinder or the lock, so it takes up space around the cylinder and gives a finished look at the face. It's a brass part measuring 1-7/8 inches in diameter.
2) Will the Baldwin 8300 collar cover the cylinder hole on my existing entry set?
It covers a 1-7/8 inch diameter footprint on the door face. Standard mortise cylinder prep is a 1-1/4 inch hole, so the collar conceals it with room to spare. Measure the exposed opening on your door before ordering; anything wider than 1-7/8 inches won't be hidden by this collar.
3) Does the Baldwin 8300 include a cylinder or is it just the ring?
Just the ring. The 8300 is a collar only, so you supply the cylinder and keying separately. Order it as an accessory alongside the lock, not as a replacement for a cylinder.
4) What finishes does the Baldwin Estate 8300 cylinder collar come in?
Four: 003 Polished Brass PVD, 031 Non-Lacquered Brass, 102 Oil Rubbed Bronze, and 190 Satin Black. Match the finish code to the rest of your Estate trim on that door. Note that 031 non-lacquered brass is a living finish that will darken and patina over time, while 003 is PVD and holds its color.
5) Is the Baldwin 8300 collar suitable for a commercial opening or a high-traffic apartment entry?
Baldwin lists the 8300 as a residential part within the Estate Series. For multi-family entries and commercial openings, spec a collar or cylinder ring from a commercial-grade line rather than this one.
6) I'm standardizing several doors in one house on Baldwin Estate trim. Can I order the 8300 collar to match?
Yes. The 8300 is part of the Estate Series, and the four finish codes (003, 031, 102, 190) are the same codes used across Baldwin Estate trim, so you can order one collar per door in a single finish and keep the openings consistent.
7) Is the Baldwin 8300 solid brass or plated pot metal?
Solid brass is the stated substrate. That matters on an exterior door face, where the collar is exposed to weather and handling, and it's why the 031 non-lacquered option can be left to patina naturally.
