BEA 10RD433EH Digital Receiver 433 MHz with Extended Hold Time 12-24 VAC/VDC

BEA 10RD433EH Digital Receiver 433 MHz with Extended Hold Time 12-24 VAC/VDC

Professional Wireless Access Control Solution

The BEA 10RD433EH Digital Receiver delivers reliable 433 MHz wireless communication for automatic door activation systems. Operating on 12 to 24 VAC/VDC power, this extended hold time receiver maintains door activation for as long as the transmitter button is pressed. Part of BEA’s 433 MHZ FAMILY, this digital receiver integrates seamlessly with compatible push button transmitters to eliminate wiring requirements and reduce installation complexity.

Professional Features & Benefits

• Extended Hold Time Operation: Maintains door open position for as long as transmitter button is pressed, providing enhanced user control and accessibility.
• Flexible Power Options: 12 to 24 VAC/VDC operation accommodates various system voltage requirements for versatile installation options.
• 433 MHz Digital Technology: Reliable radio control frequency provides consistent wireless communication with compatible BEA transmitters.
• Enhanced Accessibility Compliance: Offers wireless activation means for automatic doors, supporting users with limited mobility or disabilities.
• Wireless Push Plate Integration: Pairs with BEA push plates to eliminate wiring runs and reduce installation time and mounting hardware requirements.
• Dual Learn Modes: Delay and no-delay learn modes provide either instant or delayed activation options for proper door sequencing control.
• 433 MHZ FAMILY Compatibility: Works with BEA’s complete line of 433 MHz wireless transmitters and push button devices for system flexibility.

Technical Specifications

• Frequency: 433 MHz
• Radio Control Type: Digital
• Emitted Radio Power: -28.7 dBm (transmitter)
• Power Consumption: 3 mA (transmitter); 30 mA (receiver)
• Power: Hardwired: 1 9-volt or 3-volt battery | Handheld: 1 3-volt battery
• Input Voltage (Receiver): 12 - 24 VAC / VDC
• Contact Rating: 1.0 A @ 30 VDC | 0.5 A @ 125 VAC | 0.3 A @ 60 VDC
• Operating Temperature: 14 deg. F - 131 deg. F (-10 deg. C - 55 deg. C)
• Capacity: 100 transmitters
• LEDs: Receiver / Transmitter Learn: RED | Relay Activity: BLUE
• Dimensions Receiver: 2.125 in (W) x 1 in (H) x 2.75 in (D)
• Dimensions Transmitter: 1.375 in (W) x 0.6 in (H) x 2.75 in (D)
• Norm Conformance: CE, FCC, IC

Installation & Operation

1. Verify electrical requirements match available power supply. Confirm 12 to 24 VAC/VDC voltage and current capacity before proceeding.
2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
3. Mount the unit in the specified location ensuring adequate clearance for wiring access, ventilation, and future service requirements.
4. Route and connect wiring according to manufacturer wiring diagrams. Use appropriate wire gauge and connectors for the application.
5. Configure operational settings including delay or no-delay learn modes per application requirements for proper door sequencing.
6. Restore power and test all functions including wireless communication with paired transmitters, extended hold time operation, and integration with automatic door systems.
7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

• Commercial Building Automatic Door Systems
• Healthcare Facility Accessibility Compliance
• Educational Institution Entry Control
• Retail Store Customer Access
• Industrial Facility Personnel Entry
• Multi-Tenant Residential Access Points
• Government Building Security Integration

Why Choose BEA Quality?

BEA digital receiver technology delivers professional-grade wireless access control with 433 MHz frequency reliability and flexible power options. The extended hold time functionality and dual learn modes provide precise control for demanding automatic door applications. Engineered for commercial installations where dependable wireless activation and accessibility compliance are essential.
