BEA MS41 Series Stainless Steel Touchless Actuator with Adjustable Range and Relay Hold Time

Professional Microwave Technology Door Activation Solution

The BEA MS41 Series touchless actuator delivers germ-free door activation using advanced microwave radar technology for interior and exterior applications. This stainless steel unit provides reliable detection of moving hands, carts, or wheelchairs with adjustable hold time for ANSI standards compliance. The durable design features rounded corners and customizable illuminated ring with audible signaling, making it ideal for sterile, wash-down environments including surgical, clean room, and pharmaceutical applications.

Professional Features & Benefits

  • Microwave Radar Technology: Advanced detection field provides reliable and consistent transmission for both interior and exterior applications.
  • Versatile Detection Capability: Capable of detecting moving hands, carts, or wheelchairs for comprehensive accessibility solutions.
  • Adjustable Hold Time: Flexible timing settings offer compliance with ANSI standards for various application requirements.
  • Stainless Steel Construction: Durable design with rounded corners suits sterile, wash-down applications including surgical and pharmaceutical environments.
  • Customizable Illuminated Ring: Visual feedback with audible signaling provides clear activation confirmation for users.
  • Touchless Operation: Eliminates physical contact to reduce touchpoints and maintain sanitation in healthcare, retail, industrial, and commercial settings.
  • Sterile Environment Compatible: Designed for wash-down applications including clean room and pharmaceutical environments where hygiene is critical.

Technical Specifications

  • Technology: Microwave Doppler Radar
  • Detection Mode: Motion (bidirectional), Toggle or Timed Mode
  • Sensing Zone: 2 in - 24 in (adjustable)
  • Hold Time: 1 s - 30 s
  • Alert Settings (Audible): Silent Mode or Signal Mode
  • Alert Settings (Visual): Blue (Standby); Green (Activation)
  • Supply Voltage: 12 - 24 VAC / VDC or 5 VDC
  • Current Consumption: < 2.8 W
  • Temperature Range: -22 deg. F - 158 deg. F
  • Enclosure Rating: NEMA 4 / IP65
  • Relay: 1-Form C Solid State Relay; 1 A; 30 VAC / VDC (max)
  • Dimensions (Single Gang): 2.75 in (W) x 4.5 in (H) x 0.98 in (D)
  • Dimensions (Double Gang): 4.5 in (W) x 4.5 in (H) x 0.98 in (D)
  • Dimensions (Jamb): 1.68 in (W) x 4.5 in (H) x 0.98 in (D)
  • Wire Harness Length: 12 in
  • Material: Stainless Steel (faceplate) / ABS (center)

Installation & Operation

  1. Verify electrical requirements match available power supply and confirm current capacity before proceeding with installation.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Mount the unit in the specified location ensuring adequate clearance for wiring access, ventilation, and future service requirements.
  4. Route and connect wiring according to manufacturer wiring diagrams. Use appropriate wire gauge and connectors for the application.
  5. Configure operational settings including adjustable range and relay hold time per application requirements and ANSI standards compliance.
  6. Restore power and test all functions including detection sensitivity, hold time operation, illuminated ring function, and audible signaling.
  7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

  • Healthcare Facility Access Control
  • Surgical and Clean Room Environments
  • Pharmaceutical Manufacturing Facilities
  • Commercial Building Automatic Door Systems
  • Retail Store Entry Points
  • Industrial Facility Access Points
  • Wash-Down and Sterile Processing Areas

Why Choose BEA Quality?

BEA MS41 Series touchless actuators deliver professional-grade reliability with stainless steel construction designed for demanding sterile and wash-down environments. The advanced microwave radar technology provides consistent detection performance in both interior and exterior applications. Engineered for commercial applications where dependable touchless operation and sanitation are essential.

Manufacturer Resources

BEA Product Catalog

Product Specs

Product Type:
Touchless Actuator
Series:
MS41 Series
Subcategory:
Sensors, Switches, Relays and Timers
Commercial/Residential:
Commercial
Electronic:
Yes
Product Group:
Electronic Access Controls
Product Subgroup:
Sensors, Switches, Relays and Timers
Product Category:
Electronic Access Control
Department:
Door Hardware

BEA 10MS41-S – Frequently Asked Questions

1) What is the BEA MS41 Series touchless actuator used for?
The MS41 Series provides hands-free door activation for automatic door systems. It detects hand movement within an adjustable range to trigger door opening. Common applications include commercial entrances, healthcare facilities, and ADA-compliant access points.
2) Which door systems are compatible with this actuator?
The MS41 works with most automatic door operators that accept relay contact closure signals. It interfaces with swing door operators, sliding door systems, and revolving doors. Verify your door operator's input requirements match the relay specifications before installation.
3) How do you adjust the detection range on the MS41?
The detection range adjusts via built-in controls accessible during installation. Turn the range adjustment dial to increase or decrease sensitivity. Test the setting with hand movements at different distances to ensure proper activation without false triggering.
4) What is the stainless steel finish grade of this unit?
The MS41 features a commercial-grade stainless steel housing designed for high-traffic environments. The finish resists fingerprints and provides durability against daily use. Check the product specifications for the exact steel grade and finish type.
5) What power requirements does the MS41 need?
Power requirements vary by model configuration. Most MS41 units operate on low voltage DC power supplied by the door operator or separate power source. Verify voltage and current specifications against your system's power output before connecting.
6) Does this actuator meet ADA compliance requirements?
Touchless actuators help facilities meet ADA accessibility guidelines by providing hands-free operation. Install the unit at appropriate height and location per ADA standards. Consult local building codes for specific mounting requirements and clearances.
7) What accessories are available for the MS41 Series?
Common accessories include mounting plates, weather shields, and wiring harnesses. Some models offer interchangeable faceplates or custom graphics. Check with the manufacturer for compatible accessories specific to your MS41 model number.
8) How is the relay hold time adjusted?
The relay hold time determines how long the activation signal remains active after detection. Adjust this setting using the built-in timing control. Longer hold times work better for slower door systems while shorter times prevent unnecessary delays.
9) What mounting requirements does this unit have?
Mount the MS41 on a stable wall surface at the specified height from the floor. Use appropriate fasteners for your wall type. Ensure adequate clearance around the sensor area and access to adjustment controls. Follow the manufacturer's template for precise positioning.
10) How do you maintain the touchless actuator?
Regular maintenance includes cleaning the sensor surface with appropriate cleaners for stainless steel. Check for loose mounting hardware and verify proper detection range periodically. Avoid harsh chemicals that could damage the housing or sensor components.
11) Are there other BEA actuator models for comparison?
BEA offers various touchless actuators with different features and mounting options. Compare detection methods, power requirements, and environmental ratings when selecting alternatives. Browse our automatic door accessories section for related products.
12) What environmental conditions can the MS41 handle?
The stainless steel construction provides resistance to moisture and temperature variations in typical commercial environments. Check the IP rating and operating temperature range for your specific installation conditions. Indoor applications generally present no environmental challenges.
