Bolts 3/8-16 X 2-3/4 G5 Hxbt St-zn (Jar 50)
Additional Notes
- Other sizes and quantities available by request
Features
- Used to mount motor to machinery. Also popular in automotive and truck repair
- A cap screw made from medium carbon steel and heat-treated
Manufacturer Resources
Product Specs
- Arra Compliant:
- C
- Buy American Compliant:
- C
- Division:
- Electrical H1
- Fastener Head Height:
- 15/64 in.
- Fastener Head Type:
- Hex
- Fastener Head Width:
- 0.551 - 0.562 in.
- Fastener Height:
- 0.226 - 0.243
- Fastener Length:
- 2/3/04
- Fastener Width:
- 0.628 - 0.650
- Grade:
- 5
- Hardness:
- Rockwell C19-30
- Language Code:
- EN
- Material Standard:
- AISI 1008 - 1026
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Gr_5_Hex_Bolt_Dom_St-Zn.pdf
- Order Minimum Imperial:
- 50
- Order Minimum Uom Imperial:
- EA
- Outside Diameter:
- 0.3690 - 0.3750 IN
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 5.75 in
- Product Length:
- 3.5 in
- Product Weight:
- 2268 g
- Product Width:
- 88.9 MM
- Sub Division:
- Electrical-E H2
- Tensile Strength:
- 105000 psi minimum
- Thread Per Inch:
- 16
- Thread Standard:
- ASME B18.2.1-2012
- Voltage Rating:
- Zinc Chromate
- Wrenching Height:
- 0.16
- Yield Strength:
- 105000 psi minimum
- Department:
- Electrical
- Product Subgroup:
- Bolts
- Product Type:
- Hexagonal Bolt
- Type2:
- Hexagonal Bolt
- Series:
- G5HC and JG5HC
- Product Finish:
- Zinc
- Product Details:
- Hexagonal Bolt
- Product Material:
- Steel
Metallics JG5HC31 – Frequently Asked Questions
1) Is a Grade 5 hex bolt strong enough for mounting a motor to a machine base?
Yes, that is the intended use. The JG5HC31 is a Grade 5 medium carbon steel cap screw, heat treated, with 105,000 psi minimum tensile and 105,000 psi minimum yield and a hardness of Rockwell C19-30. Metallics lists motor mounting to machinery as the primary application, along with automotive and truck repair. For higher clamp loads you would step up to a Grade 8 bolt instead.
2) Does the Metallics JG5HC31 hex bolt meet Buy American and ARRA requirements for a public project?
Metallics flags the JG5HC31 as both Buy American compliant and ARRA compliant. Country of origin is listed as multiple, so if your spec requires documentation of a single source country, get the cert on the specific lot shipped.
3) How many bolts come in a jar of Metallics JG5HC31?
Fifty pieces, packed in a jar. The order minimum is 50 each, so the jar is the buy unit rather than a loose count. Jar weight is listed at 2268 g. Metallics notes other sizes and quantities are available by request.
4) Will a zinc plated Grade 5 bolt hold up outdoors or in a damp mechanical room?
The JG5HC31 is steel with a zinc finish, which handles indoor mechanical rooms, equipment rooms and general industrial service fine. Zinc plating is a sacrificial coating, not stainless, so for continuous wet, coastal or chemical exposure a hot dip galvanized or stainless fastener is the better call.
5) What dimensional standard do these 3/8-16 hex bolts follow, and will the heads clear a tight bracket?
Threads and head geometry follow ASME B18.2.1-2012, so the JG5HC31 interchanges with any standard 3/8-16 hex cap screw of the same length. Head height is 15/64 inch and the head measures 0.551 to 0.562 inch across the flats, with a wrenching height of 0.16 inch. If you are bolting into a recess or counterbore, those are the numbers to check for socket clearance.
6) What steel are Metallics Grade 5 hex bolts made from?
Material standard is AISI 1008 to 1026 steel, heat treated to Grade 5 properties. That lands it at Rockwell C19-30 hardness with 105,000 psi minimum tensile. It is a structural and machinery fastener, not a stainless or non magnetic one.
