Metallics JSBH404 Bolts 3/8-24 x 2 HXBT SS (Jar 100)

Fine thread. The JSBH404 is 3/8-24, meaning 24 threads per inch, so it mates with 3/8-24 fine thread nuts and tapped holes only. A 3/8-16 coarse nut will not run onto it. Shank outside diameter measures 0.3690 to 0.3750 in.

18-8 austenitic stainless gives general atmospheric corrosion resistance, which covers exterior mounting, damp mechanical rooms, and chemical or food-processing equipment. Aggressive chemical exposure, chlorides, or marine salt spray are a different story: those call for 316 stainless or another specified corrosion-resistant alloy rather than 18-8.

Head width across flats runs 0.551 to 0.562 in., which is a 9/16 inch wrench or socket. Head height is 15/64 in., so clearance under a tight bracket is minimal.

Tensile strength is 100,000 to 150,000 psi minimum with a 65,000 psi minimum yield and hardness of Rockwell B95-C32. That puts it in the range of a medium-strength fastener, but stainless cap screws are chosen for corrosion resistance rather than as a direct strength substitute. If a drawing calls out a specific SAE or ASTM grade, match the grade, not just the diameter.

They ship 100 to a jar, and 100 count is the order minimum. The jar packaging keeps loose fasteners contained on a service truck or MRO shelf rather than spilling in a bin.

The JSBH404 is flagged both ARRA compliant and Buy American compliant, which is what a government, education, or healthcare procurement file usually needs on a fastener line item. Country of origin is recorded as multiple.

The SBHC and JSBHC series runs well beyond the 3/8-24 x 2 size, and other sizes and quantities are available by request. The JSBH prefix indicates the jar-packed count; bulk-boxed equivalents exist in the same series.
