Bolts M10 x 35 HXBT SS (Jar 100)
Additional Notes
- Other sizes and quantities available by request, DIN 933 Spec for maximum width across flats on these three diameters are 17, 19 & 22 mm, respectively
Manufacturer Resources
Product Specs
- Arra Compliant:
- C
- Buy American Compliant:
- C
- Dimensional Standard:
- DIN 933
- Division:
- Electrical H1
- Fastener Head Type:
- Hex
- Fastener Head Width:
- 15.73 - 16 in.
- Fastener Height:
- 6.22 - 6.58
- Fastener Length:
- 35mm
- Fastener Width:
- 17.77
- Grade:
- A-2
- Language Code:
- EN
- Material Standard:
- ISO 3506
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-Hex_Hd_Metric_Bolt_18-8_and_316_SS.pdf
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- CT
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 5.75 in
- Product Length:
- 3.5 in
- Product Weight:
- 2994 g
- Product Width:
- 88.9 MM
- Sub Division:
- Electrical-E H2
- Thread Pitch:
- 1.5
- Thread Standard:
- ISO 724|ISO 965-1
- Wrenching Height:
- 4.35
- Department:
- Electrical
- Product Subgroup:
- Bolts
- Product Type:
- Hexagonal Bolt
- Type2:
- Hexagonal Bolt
- Series:
- JMSBHC
- Product Details:
- Hexagonal Bolt
- Product Material:
- 18-8 Stainless Steel
Metallics JMSBHC106 – Frequently Asked Questions
1) What thread does the Metallics JMSBHC106 M10 bolt use, and will it take a standard M10 nut?
It's an M10 bolt with a 1.5 mm thread pitch, which is the standard coarse metric pitch, so it mates with any standard M10 nut or M10 x 1.5 tapped hole. Threads are cut to ISO 724 and ISO 965-1. If your assembly uses an M10 x 1.25 fine thread, this will not engage.
2) Is this M10 x 35 hex bolt stainless, and is it suitable for outdoor or damp electrical work?
The bolt is 18-8 stainless steel, property class A-2 to ISO 3506, so it holds up in wet and outdoor conditions far better than plain or zinc-plated steel. A-2 (18-8) is not the marine grade; for chloride exposure such as coastal or pool environments, step up to 316 stainless.
3) What wrench or socket size do I need for these Metallics M10 hex bolts?
These are hex head bolts built to DIN 933, and DIN 933 puts the maximum width across flats at 17 mm for the M10 diameter. A 17 mm socket or wrench is what you want on site.
4) How are these sold, and is there a minimum order?
They ship in a jar of 100 pieces, and 100 count is the order minimum, so the jar is the buying unit. Total weight of the jar is listed at 2994 g.
5) Do these bolts come with nuts and washers?
No. The jar of 100 is bolts only, so order M10 nuts and M10 washers separately. Match them in 18-8 stainless to avoid mixing metals in the joint.
6) Will these M10 bolts satisfy a Buy American or ARRA requirement on a federal job?
Metallics flags the JMSBHC106 as ARRA compliant and Buy American compliant, with country of origin China. Submit it against your spec with both of those on record, since the two programs treat origin differently depending on the contract.
7) Can I get this same stainless hex bolt in other lengths or diameters?
Yes, other sizes and quantities in the JMSBHC line are available by request. Metallics covers three diameters in this family, with DIN 933 widths across flats of 17, 19 and 22 mm, so the M10 sits at the smallest of the three.
