Bolts M10 x 50 HXBT SS (Jar 100)
Additional Notes
- Other sizes and quantities available by request, DIN 933 Spec for maximum width across flats on these three diameters are 17, 19 & 22 mm, respectively
Manufacturer Resources
Product Specs
- Arra Compliant:
- C
- Buy American Compliant:
- C
- Dimensional Standard:
- DIN 933
- Division:
- Electrical H1
- Fastener Head Type:
- Hex
- Fastener Head Width:
- 15.73 - 16 in.
- Fastener Height:
- 6.22 - 6.58
- Fastener Length:
- 50mm
- Fastener Width:
- 17.77
- Grade:
- A-2
- Language Code:
- EN
- Material Standard:
- ISO 3506
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-Hex_Hd_Metric_Bolt_18-8_and_316_SS.pdf
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- CT
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 5.75 in
- Product Length:
- 3.5 in
- Product Weight:
- 3248 g
- Product Width:
- 88.9 MM
- Sub Division:
- Electrical-E H2
- Thread Pitch:
- 1.5
- Thread Standard:
- ISO 724|ISO 965-1
- Wrenching Height:
- 4.35
- Department:
- Electrical
- Product Subgroup:
- Bolts
- Product Type:
- Hexagonal Bolt
- Type2:
- Hexagonal Bolt
- Series:
- JMSBHC
- Product Details:
- Hexagonal Bolt
- Product Material:
- 18-8 Stainless Steel
Metallics JMSBHC1050 – Frequently Asked Questions
1) What thread does the Metallics JMSBHC1050 M10 bolt use, and will it take a standard M10 nut?
It is an M10 x 1.5 thread, the coarse metric pitch, cut to ISO 724 and ISO 965-1. Any standard coarse M10 nut or tapped M10 hole will take it. If your hole is M10 x 1.25 or finer, this bolt will not thread in.
2) What size wrench or socket fits this M10 hex bolt head?
DIN 933 sets the maximum width across flats for an M10 hex bolt at 17 mm, so a 17 mm wrench or socket is the right tool. The listed fastener width of 17.77 reflects the across-corners measurement, not the flats.
3) Will these stainless bolts hold up outdoors or in a damp mechanical room?
They are 18-8 stainless steel, A-2 class under ISO 3506, which handles outdoor and wet interior service without rusting. For saltwater or chloride exposure (coastal rails, pool chemistry, wash-down food areas), step up to 316 stainless instead.
4) Do these M10 stainless bolts qualify for a federally funded job?
Metallics flags the JMSBHC1050 as both ARRA compliant and Buy American compliant. Country of origin is China, so if your specification demands domestic melt and manufacture rather than general Buy American treatment, verify against your contract language.
5) How many bolts come in a jar of Metallics JMSBHC1050, and can I buy fewer?
They ship 100 to a jar, and 100 count is the order minimum, so the jar is the smallest unit. Total packed weight is 3248 g.
6) Are nuts and washers included with the JMSBHC1050 jar?
The jar is 100 hex head bolts only. Nuts, flat washers, and lock washers in A-2 18-8 stainless have to be ordered separately, and you want them in matching stainless so you do not set up galvanic corrosion with plated steel hardware.
7) What is the exact part number if I need other M10 lengths or different diameters?
This one is JMSBHC1050 in the Metallics JMSBHC series of metric hex head stainless bolts. Other sizes and quantities in the series are available by request. DIN 933 maximum width across flats runs 17, 19, and 22 mm for the three diameters in the family.
