Burndy WEEB-LUG-6.7 Lay-In Grounding Lug, Tin-Plated Copper

The Burndy WEEB-LUG-6.7 is a lay-in grounding lug assembly engineered for dependable equipment grounding and bonding connections in commercial and industrial electrical systems. This assembly pairs a Tin-Plated Copper lug body with an integrated WEEB Washer, and arrives fully assembled with (1) 1/4-28 hex screw and (1) 1/4-20 x 3/4 hex screw already installed for immediate use. Sized for a 14-6-AWG conductor range, the WEEB-LUG-6.7 ships 100 assemblies per box, making it well suited for contractors and facilities that need consistent, code-compliant grounding hardware on hand. As a mechanical grounding connector, it is well suited for panelboards, enclosures, and equipment grounding conductor terminations where a secure, reusable connection is required.

Key Features

  • Conductor Range: Accepts 14-6-AWG conductors for flexible grounding and bonding wire sizing.
  • Durable Construction: Tin-Plated Copper lug body resists corrosion and maintains strong electrical conductivity.
  • Lay-In Design: Lay-in lug configuration with an integrated WEEB Washer simplifies wire placement and delivers a dependable grounding connection.
  • Fully Assembled Hardware: Each assembly includes (1) 1/4-28 hex screw and (1) 1/4-20 x 3/4 hex screw, pre-assembled and ready to install.
  • Bulk Packaging: Supplied 100 assemblies per box for job-site efficiency.
  • Mechanical Connector: Classified as a mechanical grounding connector, providing a secure set-screw style termination for grounding conductors.
  • WEEB Washer: Integrated WEEB Washer provides a reliable bonding point for a secure grounding conductor termination.

Technical Specifications

  • Conductor Range: 14-6-AWG
  • Product Type: Mechanical

Typical Applications

  • Electrical Grounding and Bonding Systems
  • Equipment Grounding Conductor Terminations
  • Commercial and Industrial Electrical Installations
  • Panelboard and Enclosure Grounding
  • Data Center and Facility Grounding Systems
  • Renovation and New Construction Wiring

Why Burndy?

Burndy's WEEB-LUG-6.7 combines a Tin-Plated Copper lug with fully assembled 1/4" hardware to deliver a dependable, ready-to-install grounding connector for the 14-6-AWG conductor range. The lay-in design and integrated WEEB Washer help ensure a secure grounding connection for professional electrical work. Supplied 100 assemblies per box, it also simplifies inventory management for contractors and facility maintenance teams.

Manufacturer Resources

Spec Sheet

Product Specs

list_batch:
BURNDY-20260915
Wire Size:
14-6-AWG
Plating:
Tin Plated
Product Type:
Grounding Connector
Product Material:
Copper
Department:
Electrical
Product Subgroup:
Grounding & Bonding
Product Group:
Grounding & Bonding

Burndy WEEB-LUG-6.7AS – Frequently Asked Questions

1) What wire sizes will the Burndy WEEB-LUG-6.7 grounding lug accept?
The WEEB-LUG-6.7 lay-in lug takes 14 through 6 AWG grounding and bonding conductors, so it covers everything from a #14 equipment grounding conductor up to a #6 solid or stranded ground run. If your ground wire is larger than 6 AWG, this is not the lug for it.
2) Does the Burndy WEEB-LUG-6.7 come with mounting screws, or do I have to supply my own?
It ships fully assembled with the hardware already in place: one 1/4-28 hex screw and one 1/4-20 x 3/4 hex screw. Nothing else to order to mount it and land the conductor.
3) What does the WEEB washer on this Burndy lug actually do?
The integrated WEEB washer is the bonding element. It gives the lug a reliable metal-to-metal bonding point at the mounting surface so the grounding conductor termination is electrically continuous with the equipment it is screwed to, rather than relying on the screw thread alone.
4) Is the Burndy WEEB-LUG-6.7 suitable for outdoor or damp electrical enclosures?
The lug body is copper with tin plating, which is the standard corrosion-resistant finish for grounding connectors and holds up better than bare copper in damp or outdoor enclosures. The tin also keeps the contact surface clean where it meets aluminum or galvanized equipment.
5) Lay-in lug or a compression ground connector - which should I use for equipment grounding?
A lay-in lug like the WEEB-LUG-6.7 is a mechanical, set-screw style termination: you lay the conductor into the open channel and tighten the screw, and it can be loosened and re-terminated later. A compression connector is crimped once and is permanent, needing a die tool. For panelboards, enclosures, and equipment grounding conductor terminations where a serviceable connection matters, the mechanical lay-in is the one to use.
6) What is the exact Burndy part number for this grounding lug assembly?
Order it as WEEB-LUG-6.7AS from Burndy. The AS suffix is the fully assembled version, shipped with the 1/4-28 and 1/4-20 x 3/4 hex screws already installed.
7) How is the Burndy WEEB-LUG-6.7 packaged for a large job?
It comes 100 assemblies to a box, which suits contractors and facility teams grounding a run of panelboards, enclosures, or racks and wanting one part number on the shelf rather than a mix.
