Burndy YA362LN 600 kcmil Copper 2-Hole Compression Lug, 1/2" Stud

Burndy YA362LN 600 kcmil Copper 2-Hole Compression Lug, 1/2" Stud

(No reviews yet) Write a Review

Model: YA362LN

In Stock (leaves warehouse same day if ordered before 3pm ET)

$29.56
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Burndy YA362LN 600 kcmil Copper 2-Hole Compression Lug, 1/2" Stud

The Burndy YA362LN is a 2-hole compression lug engineered for 600 kcmil copper conductors, featuring a 1/2" stud, a 1-3/4" strip length, and 1.75" hole spacing on a standard chamfered and skived barrel with a tin-plated finish for durable, corrosion-resistant connections. Part of the HYLUG™ series, this terminal is rated up to 35kV at 90°C and is both UL Listed and CSA Approved, making it well-suited for demanding power distribution and code conductor grounding applications. The two-hole pad, with a 1.74" pad width and 0.52" bolt hole size, delivers a secure, vibration-resistant termination for professional electrical work.

Key Features

  • Conductor Size: Sized for 600 kcmil copper conductors with a 1-3/4" strip length.
  • 2-Hole Pad: 1/2" stud with 1.75" hole spacing and a 1.74" pad width for secure two-bolt mounting.
  • Durable Construction: Copper barrel with a tin (electro) plated finish for corrosion resistance and reliable long-term conductivity.
  • Barrel Style: Standard barrel with a chamfered and skived entry for easy conductor insertion.
  • Voltage Rating: Rated up to 35kV with a 600V minimum rating and a 90°C operating temperature.
  • Die Index: Compatible with die index 22/472 for correct crimp tool selection.
  • Compact Dimensions: 5.23" overall length, 1.19" outside diameter, and a 0.52" bolt hole size.

Certifications & Compliance

  • UL Listed
  • CSA Approved
  • RoHS Compliant (CM Status)

Technical Specifications

  • Mounting Holes: 2
  • Insulated: Yes
  • Length Overall: 5.23 in
  • Application: For Code Conductor
  • Conductor Material: Copper
  • Plating Type: Tin - Electro Plated
  • Bolt Hole Size: 0.52 in
  • Pad Width: 1.74 in
  • Stud Size: 1/2 in
  • Trade Name: HYLUG™
  • CSA Approved: Yes
  • KVA Rating: 35 kV
  • Barrel Style: Chamfered
  • Outside Diameter: 1.19 in
  • Minimum Voltage: 600
  • Maximum Voltage: 35000
  • Product Material: Copper
  • Strip Length: 1-3/4 in
  • Product Type: Terminal
  • Connector Type: Standard Barrel
  • Die Index: 22;472
  • RoHS Compliance Status: CM
  • UL Listed: Yes

Typical Applications

  • Power Distribution and Grounding Connections
  • Code Conductor Terminations up to 35kV
  • Commercial and Industrial Electrical Installations
  • Utility and Switchgear Wiring
  • Copper Conductor Compression Termination

Why Burndy?

Burndy's HYLUG™ series compression lugs combine tin-plated copper barrels, chamfered and skived entries, and precise die index compatibility for a dependable, code-compliant termination every time. With UL Listing and CSA Approval backing the YA362LN, electrical professionals can count on consistent performance in demanding power distribution and grounding applications.

Manufacturer Resources

Spec Sheet

Product Specs

list_batch:
BURNDY-20260915
Wire Size:
600 KCMIL
Mounting Holes:
2
Plating:
Tin Plated
Insulated:
Yes
Dimension - Length Overall inch:
5.23 in
Color Code:
Green
Feature - Barrel Type:
Standard
Dimension - Z inch:
0.64 in
Dimension - N inch:
0.63 in
Conductor - Copper Str Size:
600 kcmil
Physical Attribute - Tongue Type:
Standard
Conductor Material:
Copper
Plating Type:
Tin - Electro Plated
Dimension - Bolt Hole Size inch:
0.52 in
Sub Brand:
HYLUG
UPC:
781810521472
Dimension - D inch:
3.02 in
Dimension - Pad Width inch:
1.74 in
Dimension - Stud Size inch:
1/2
Trade Name:
HYLUG™
Product Details:
Standard Barrel, Tin Plated
Certification - CSA Approved:
Yes
Physical Attribute - Number of Holes:
2
Rating - KVA:
35 kV
Feature - Barrel Style:
Chamfered
Dimension - B Length fraction:
1-3/8 in
Plated:
Y
Dimension - Outside Diameter inch:
1.19 in
Dimension - L Length Overall mm:
133 mm
Dimension - Bolt Size fraction:
1/2
Rating - Minimum Voltage:
600
Voltage - Maximum:
35000
Minimum Pack Quantity:
1
Conductor - Copper Str Size Range:
600 kcmil
Dimension - Strip Length inch:
1-3/4
Certification - UL Recognized:
No
Certification - cULus:
No
Product Type:
Compression Lug
Connector Type:
STANDARD BARREL
Certification - ETL:
No
Die Index:
22;472
Dimension - B Length inch:
1.38 in
Standards - RoHS Compliance Status:
CM
UL Listed:
Yes
Dimension - Hole Size mm:
14 mm
Physical Attribute - Tongue Angle:
Straight
Product Material:
Copper
Product Size:
1/2"
Department:
Electrical
Product Group:
Wire Connectors & Terminals
Product Subgroup:
Lugs & Terminals
Application:
For Code Conductor

Burndy YA362LN – Frequently Asked Questions

1) What conductor size does the Burndy YA362LN lug take?
The YA362LN is a single-size lug for 600 kcmil stranded copper only. It is not a range lug, so 500 kcmil or 750 kcmil conductors need a different catalog number. Strip the conductor back 1-3/4 inches so the barrel is fully filled before crimping.
2) Will the YA362LN bolt to a 1/2 inch two-hole bus pad?
Yes. The two-hole tongue is drilled for 1/2 inch studs with 0.52 inch bolt holes on 1.75 inch centers, which is the standard NEMA two-hole spacing for 1/2 inch hardware. Pad width is 1.74 inches, so confirm your bus or breaker pad is at least that wide.
3) What die do I set my crimp tool to for a Burndy YA362LN?
Crimp with die index 22 (color code 472 / green marking). Get the die right, the crimp is what makes the connection code compliant, and an undersized die on a 600 kcmil barrel will not hold.
4) Can this Burndy compression lug be used on medium voltage cable terminations?
Yes, the YA362LN is rated 600V minimum up to 35kV at 90 degrees C, so it works for both 600V power distribution and medium voltage terminations up to 35kV. It's UL Listed and CSA Approved.
5) Is the YA362LN suitable for aluminum conductor?
No. It is a copper-body lug sized specifically for 600 kcmil copper stranded conductor. For aluminum or dual-rated AL9CU terminations you need a different lug, not this one.
6) How much room do I need in the enclosure for a 600 kcmil Burndy HYLUG?
Overall length is 5.23 inches (133 mm) with a 1.19 inch barrel outside diameter. Barrel length is 1-3/8 inches. Allow for the cable bending radius on top of that when laying out a tight gutter or termination compartment.
7) Does the tin plating on this Burndy lug matter for outdoor or damp locations?
It helps. The copper barrel is electro tin plated, which resists corrosion at the crimp and at the bolted interface, and it is the preferred surface where the lug lands on a tinned or plated bus. Useful in utility, outdoor pad-mount, and industrial wash-down areas.
8) Does the chamfered barrel make a difference when installing 600 kcmil cable?
Yes, on a conductor that size it does. The barrel entry is chamfered and skived, so a fanned 600 kcmil strand bundle feeds in without hanging up strands on the lip, which is the usual cause of a partially seated crimp.
9) Can I order a single Burndy YA362LN or do they come in a box?
Minimum pack quantity is 1, so a single lug can be ordered rather than a full carton. Handy when you only need one or two for a service change.
10) Is the YA362LN RoHS compliant for a government or institutional spec?
It carries RoHS compliance status CM, plus UL Listing and CSA Approval. That covers the usual documentation asks on public and institutional electrical submittals.
