Cal-Royal Cal-Royal CUSSS-61 CUSH Shoe Support CAL-CUSSS-61

Cal-Royal CUSSS-61 CUSH Shoe Support Bracket for Door Closer Arms

(No reviews yet) Write a Review

Model: CUSSS-61-ALUM
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$20.56
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Cal-Royal CUSSS-61 CUSH Shoe Support Bracket for Door Closer Arms

The Cal-Royal CUSSS-61 CUSH Shoe Support is a purpose-built anchorage accessory designed for use with CUSH arms on commercial door closers. This component provides secure anchorage for the fifth screw used with CUSH arms in applications where the door reveal is less than 3-1/16" (78 mm), ensuring a stable and properly supported installation even in narrow reveal conditions. As a precision accessory within the Door Controls product category, the CUSSS-61 is engineered to integrate seamlessly with compatible CUSH arm assemblies for commercial door hardware applications.

Key Features

  • Reveal Compatibility: Designed specifically for door reveal conditions less than 3-1/16" (78 mm), providing reliable anchorage where standard mounting may be insufficient.
  • Fifth Screw Anchorage: Provides dedicated anchorage support for the fifth screw used with CUSH arms, reinforcing the overall stability of the closer arm assembly.
  • Surface Mounted Design: Configured as a surface mounted accessory for straightforward integration with existing door closer hardware.
  • Commercial-Grade Component: Built for commercial door control applications, supporting consistent performance in high-traffic environments.
  • Compact Support Accessory: Functions as a dedicated parts and accessories item, allowing precise supplementation of CUSH arm anchorage without replacing the entire closer assembly.

Technical Specifications

  • Subcategory: Surface Mounted
  • Product Group: Door Controls
  • Product Subgroup: Parts and Accessories
  • Product Type: Parts and Accessories
  • Commercial/Residential: Commercial
  • Product Model: CUSSS-61
  • Product Category: Door Controls
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Cal-Royal CUSSS-61?

Cal-Royal door control accessories are engineered to provide reliable anchorage and support for commercial door closer installations where standard mounting configurations fall short. The CUSSS-61 CUSH Shoe Support addresses a specific installation challenge—narrow reveal conditions under 3-1/16"—delivering a dependable, purpose-built solution for professionals working with CUSH arm door closer systems in demanding commercial environments.

Product Specs

Subcategory:
Surface Mounted
Product Group:
Door Controls
Product Subgroup:
Parts and Accessories
Product Type:
Parts and Accessories
Commercial/Residential:
Commercial
Product Model:
CUSSS-61
Product Category:
Door Controls
Department:
Door Hardware

Cal-Royal CUSSS-61-ALUM – Frequently Asked Questions

1) What is the Cal-Royal CUSSS-61 CUSH shoe support actually for?
The CUSSS-61 is a small anchorage bracket that gives the fifth screw on a CUSH arm something solid to bite into. On a CUSH (stop-in-arm) closer the shoe takes the abuse of the door hitting its stop, and when the reveal is tight there isn't enough frame face left to land that fifth fastener properly. The bracket adds that anchorage point. It surface mounts, and it's a supplement to a CUSH arm assembly, not a replacement for the closer or the arm.
2) Is the CUSSS-61 the same thing as the LCN 1260-30 cush shoe support?
They do the same job at the same trigger point. The LCN 1260-30 is a cush shoe support for door closers with 3-1/16 inch reveal compatibility, from the LCN 1260 Series, and the Cal-Royal CUSSS-61 covers reveals under 3-1/16 inches on Cal-Royal CUSH arms. They are not interchangeable parts, though. Buy the one that matches the brand of closer arm on the door: Cal-Royal arm, Cal-Royal bracket; LCN 1260 closer, the 1260-30.
3) The reveal on my opening is deeper than 3-1/16 inch. What do I use instead of a CUSH shoe support?
A shoe support is only needed where the reveal is less than 3-1/16 inch (78 mm) and the fifth screw on the CUSH arm has nothing solid to land on. With a deeper reveal the arm shoe mounts on its own and no support is required. If the problem is that the frame face will not take the standard closer fastener pattern, the LCN 1260-18QF Quick Fix Bracket Kit is a 1000 Series mounting bracket kit rather than a shoe support, and it addresses mounting rather than fifth-screw anchorage.
4) My closer arm is worn out, not just loose. Do I need a whole new closer?
No. The CUSSS-61 only adds shoe anchorage, so it won't fix a worn or bent arm. Replacement arms are a separate part, and ZenSupply carries them by closer family: the Deltana DCCA4041 cushion arm for the DC40 closer, the Deltana DCHA1050 hold open arm for the DC10, and the Dorma 15323 1-1/2 inch offset bottom arm with cover. Pick by the closer body already on the door.
5) Should I use a CUSH arm with a shoe support, or a closer with a hold open track?
Different jobs. A CUSH arm carries the stop in the arm itself, so the door's overswing is controlled at the shoe, which is why the anchorage matters and why the CUSSS-61 exists on tight reveals. A track closer runs the arm in a channel and can hold the door open: the LCN 4040SEH-3038 hold open track is a 4000 Series track accessory, and the LCN 4040SE-3038 standard track is for fire and life safety door closers in the 4040SE Series. Pick CUSH when you need a built-in stop and no wall stop is possible; pick a track when you want hold open or a lower profile.
6) Will a cushion arm work in place of the CUSSS-61 shoe support?
No, they are different parts. The Deltana DCCA4041 is a cushion arm for the DC40 door closer, meaning it is the arm assembly itself. The Cal-Royal CUSSS-61 is not an arm; it is the bracket that anchors the fifth screw of a CUSH arm on narrow reveals. A job that needs a CUSH arm replaced needs an arm such as the DCCA4041 on a DC40 closer; a job where the arm is fine but the shoe has no backing needs the CUSSS-61.
7) My closer uses a track instead of a CUSH arm. Does the CUSSS-61 apply?
No. Track-mounted closers carry the arm roller in a track across the head, so there is no arm shoe on the frame face and no fifth screw to anchor. For those, the part in question is the track itself: the LCN 4040SE-3038 is a standard track for fire and life safety door closers in the 4040SE Series, and the LCN 4040SEH-3038 is the hold open version. The Cal-Royal CUSSS-61 belongs only on installations using CUSH arms.
8) Is the Cal-Royal CUSSS-61 suitable for a high traffic commercial entrance?
It's a commercial door control part, and the anchorage job it does matters most on doors that get slammed, since the CUSH shoe absorbs the stop load every cycle. Typical use is office buildings, schools, healthcare, retail, warehouse, multi-tenant residential, and municipal buildings. For a property manager standardizing a building, it's an inexpensive line item to add wherever CUSH arms are going onto tight reveal frames.
9) How many CUSSS-61 brackets do I order for a pair of doors?
One per closer. Each CUSH arm has one shoe and one fifth screw, so a pair of doors with a closer on each leaf takes two brackets. Order the finish to match each arm; all three finishes, aluminum, duronodic, and gold, are stocked.
10) What is the difference between a CUSH shoe support and an offset bottom arm?
They solve different problems. The Dorma 15323 is a 1-1/2 inch offset bottom arm with cover, a standard duty part that connects a closer to the bottom of the door and is not fire rated. The Cal-Royal CUSSS-61 is not a load-carrying arm at all; it is the bracket that gives the fifth screw of a CUSH arm something to anchor into where the reveal is less than 3-1/16 inch (78 mm). Ordering one when the other is needed leaves the closer without the piece the opening actually calls for.
11) Can I match the CUSSS-61 shoe support to the closer finish already on my doors?
The Cal-Royal CUSSS-61 comes in aluminum, duronodic, and gold, so the support can be finished to blend with the closer arm it backs up rather than standing out on the frame face. Peer arms and tracks such as the Deltana DCCA4041 cushion arm for the DC40 and the Dorma 15323 offset bottom arm with cover are separate assemblies and do not carry the CUSSS-61 finish set. For a property standardizing across many openings, matching the support finish to the arm keeps the frame face consistent door to door.
